Bruce Ellis, President, BRUDEN-OSSG
|
|
|
|
|
|
|
|
OpenVMS processes
provide an environment in which programs can be executed. This environment
includes software context, hardware context, and virtual address space. The "divide and conquer" approach
to problem solving allows different programs, running simultaneously under
different processes, to take on parts of a task concurrently. To support this design, the processes need
methods to communicate with one another and to synchronize, or coordinate,
activities between the processes.
OpenVMS provides
several methods for interprocess synchronization and communication. Methods for
interprocess communication include shared files, logical names, mailboxes, and
global sections (shared virtual memory). Inter-process synchronization methods
include common event flags, mailboxes, and lock management services.
Shared files are
generally slow methods of communication. Logical names are potentially faster
than shared files, but extensive use may fragment paged pool. Global sections are probably the fastest form
of interprocess communication. The one major drawback to each of these methods
is that there is no built-in signaling mechanism to notify the target process
that there is a need to obtain the new data.
In each case, the application could poll for new data, but this wastes
CPU time and/or may cause delays in event notification.
For synchronization
within a single system, common event flags have limited name space. You can
only wait on one common event flag cluster at a time and there are only 32
(single-bit) event flags per cluster. Lock management system services are
designed more for coordination of activities than signaling, although signaling
mechanisms can be implemented using the lock management services.
Mailboxes provide
methods that allow processes to communicate with one another and to receive
notification that there is data to be processed. In addition, there is an
implicit queuing mechanism for multiple messages that have been written to the
mailbox. The programming interface to mailboxes is simple to implement and can
be written in just about any programming language, including DCL.
|
|
|
|
|
|
Mailboxes are
pseudo-devices, similar to UNIX-style pipes. However, mailboxes allow
bi-directional communication, i.e., a single process can read and write the
same mailbox. Messages written to a mailbox are queued in first-in-first-out
fashion. To implement pipe-oriented communication, channels can be assigned to
a mailbox, such that the mailbox channel can only be written, or conversely,
can only be read.
A mailbox can have
multiple writers and multiple readers, although multiple reader designs are
probably rarer than multiple writers. It is usually easier to implement a
single reader of a mailbox (Figure 1).
Figure 1. Sample Mailbox Design
When the writer wants
to get messages back from the reader, it may use various methods, including
creating a separate mailbox and passing along the mailbox unit number to the
reader. The "reader" would assign a channel to the target mailbox
unit and send a response as in Figure 2.
Figure 2. Communication between Mailbox Writer and Reader
In general, a mailbox
read operation does not complete until there is a corresponding write
operation. Similarly, write operations do not complete until there is a
corresponding read operation. Applications that perform synchronous read or
write operations will stall, waiting on an event flag (in the scheduling state
LEF), until the counterpart operation is issued by another process.
Mailbox operations
can be performed using high-level language I/O constructs, but more commonly
are processed using the QIO (sys$qio) system service. The specifics of QIO
operations on mailboxes are documented in chapter 4 of the OpenVMS I/O User's Reference Manual.Before you can issue a QIO on a device, a channel must be
assigned. The channel identifies the
device on your QIO system service calls. For more information on QIO and
channels see chapter 23 of the OpenVMS Programming
Concepts Manual.
Mailbox writes can be
forced to complete immediately upon queuing by using a QIO system service
function modifier (IO$M_NOW). This mechanism is different than performing an
asynchronous QIO, in that the I/O request is not pending. What this means is
that if a program that has issued a write using the IO$M_NOW modifier exits,
its write stays queued to the mailbox, as long as some process on the system is
interested in the mailbox (has a channel assigned to it). If a write was issued
asynchronously without the IO$M_NOW modifier and the program exits, the write
is canceled (when the channel to the mailbox is deassigned) and the write is
lost.
Data that is written
to the mailbox can be in any form and can vary in size. The mailbox driver
simply treats the data as an array of bytes. The writer identifies the number
of bytes being written to the mailbox. The size can vary from 0 to 64,000
bytes, dependent on the maximum message size assigned to the mailbox. The
64,000 byte limit is based on the fact that mailbox messages are allocated from
non-paged dynamic memory (a.k.a. non-paged pool). Pool packets contain a word
(16-bit) sized field to identify the amount of pool that the packet occupies.
The mailbox reader
must supply a buffer that is large enough to hold the largest data item that
will be written to the mailbox. To determine the number of bytes actually
written, the reader should pass an I/O status block on a QIO to the mailbox
driver. The reader can examine the size field in the I/O status block upon
completion of the read.
|
|
|
|
|
|
Before a mailbox can
be used, it must be created. Mailbox creation is performed using the Create
Mailbox (sys$crembx) system service. When a mailbox is created, it is assigned
a name of the form MBAu, where u is a unit number assigned by
OpenVMS. Prior to V8.2, OpenVMS limited
the unit numbers on mailboxes to 9999. Additionally, mailbox creation and
deletion required sequential scans of all existing units, which could be a slow
process. V8.2, and greater, systems were modified to support up to 32,767
mailbox units. The I/O database was optimized to speed the creation and
deletion of mailboxes.
The program does not
generally have knowledge of the mailbox device name that it is creating, as
OpenVMS dynamically defines the name. To
associate multiple processes to the same mailbox, processes usually identify
the mailbox using a logical name. The logical name is passed by descriptor as
the seventh argument to the sys$crembx system service call.
To create a
mailbox at the DCL level you can use the command CREATE/MAILBOX.
|
|
|
|
|
|
The first parameter
to sys$crembx is a flag that identifies whether the mailbox is a temporary or
permanent mailbox. If the flag is set you get a permanent mailbox, otherwise you
get a temporary mailbox.
Temporary mailboxes
require TMPMBX privilege to create. They are deleted when all channels to the
mailbox have been deassigned. The logical name passed to sys$crembx is
cataloged in the logical name table identified by the logical name
LNM$TEMPORARY_MAILBOX. By default, this logical name is assigned to
LNM$JOB. Therefore, by default, using
the logical name passed to the sys$crembx, system service associates processes
in the same job to the same mailbox.
Changes to this logical name are best made within the program, in user
mode. Changes made at the DCL level may cause problems with SPAWN/ATTACH
commands. If you do choose to change the logical name LNM$TEMPORARY_MAILBOX at
the DCL level, make sure to change it in the LNM$PROCESS_DIRECTORY logical name
table.
Permanent mailboxes
require PRMMBX privilege to create and delete. They must be explicitly deleted
using the sys$delmbx system service. The mailbox is actually deleted after all
channels to the mailbox have been deassigned. The logical name passed to
sys$crembx is cataloged in table identified by the logical name
LNM$PERMANENT_MAILBOX. This logical name is set to LNM$SYSTEM by default.
If you are using DCL
to create a mailbox, you can define that the mailbox will be temporary or
permanent using the /TEMPORARY or /PERMANENT qualifiers, respectively. The default qualifier is /TEMPORARY. Just
like the sys$crembx system service, you need TMPMBX privilege to create
temporary mailboxes and PRMMBX privilege to create permanent mailboxes. You
also need CMEXEC privilege to create a temporary mailbox. This privilege is
required to allow the mailbox to be created in supervisor mode. The plan is to
remove this restriction in the future. You may also need SYSNAM or GRPNAM
privilege to create the logical name associated with the mailbox in the
appropriate logical name table.
Permanent DCL-created
mailboxes can be deleted using the DELETE/MAILBOX command. When all channels
are deassigned the mailbox will go away. Currently, there is no supported way
to deassign a channel to a DCL-created mailbox without logging out. Therefore,
there is no supported way to delete a temporary mailbox without logging out. We
at BRUDEN-OSSG, of course, have a method to get the channel deassigned.
Example 1. Viewing the Temporary and Permanent
Logical Name Table Assignments
$ show logical/table=lnm$system_directory *mail*
(LNM$SYSTEM_DIRECTORY)
"LNM$PERMANENT_MAILBOX" = "LNM$SYSTEM"
"LNM$TEMPORARY_MAILBOX" = "LNM$JOB"
$
|
When the mailbox has
been created, the channel number assigned to the mailbox is returned to the
address passed as the second parameter to the sys$crembx system service. If
multiple processes are going to be accessing the same mailbox and one process
is guaranteed to create the mailbox, the rest of the processes can simply
assign channels to the mailbox.
If the mailbox
creator is not guaranteed to be a specific process, all processes can call the
sys$crembx system service. After the
mailbox has been created, the sys$crembx system service simply assigns a
channel to the mailbox. Care should be
taken to make sure that arguments to the sys$crembx system service match for
all users of the same mailbox. If one process sets the prmflg (permanent flag) and
another passes a zero for the argument, you end up creating two different
mailboxes (one permanent and one temporary). Additionally, parameters used to
size the mailbox and establish protections are assigned by the first process
calling the service (the process that actually creates the mailbox).
|
|
|
|
|
|
Protection on a
mailbox is set when the mailbox is created. The fifth argument to sys$crembx
identifies the protection mask. If the protection mask is 0, the template
protection mask is used. This mask defaults to allowing all access to all UIC
categories. In the protection mask, bits
<15:12> identify world, bits <11:8> group, bits <7:4> owner,
and bits <3:0> system access. The categories for each mode are LPWR (Logical,
Physical, Write, and, Read). Bits clear allow access. Bits set deny access. Logical access is
required for any other form of access. Physical access is ignored. A setting of
the hex value 0xF000 would allow all access for System, Owner, and Group,
denying access for the World category. The setting 0xF200 would write access
for the Group category and all access for the World category.
Example 2. Sample Call to sys$crembx Disabling World Access to a given Mailbox
/* Assign a channel to the mailbox. */
status = sys$crembx(0,&mbx_chan,0,0,0xF000,0,&mbx,0,0);
check(status);
|
Example 3. Viewing the Protections from the Mailbox Created in Example 2.
$ SHOW DEVICE MBA28282:/FULL
Device MBA28282:, device type local memory mailbox, is online, record-oriented
device, shareable, mailbox device.
Error count 0 Operations completed 0
Owner process "" Owner UIC [JAVA,ELLIS]
Owner process ID 00000000 Dev Prot S:RWPL,O:RWPL,G:RWPL,W
Reference count 1 Default buffer size 256
$
|
In addition to the
sys$crembx argument for protections, there is an IO$M_SETPROT function modifier
on the IO$_SETMODE function that accepts a protection mask on the P2 argument
to the sys$qio system service. You can also set up objects rights on your
mailbox.
DCL-created mailboxes
have protections assigned using the /PROTECTION qualifier on the CREATE/MAILBOX
command.
|
|
|
|
|
|
To understand sizing
issues that relate to mailboxes we should take a different view of a mailbox.
When a mailbox is created, OpenVMS creates a data structure called a Unit
Control Block (UCB) in non-paged pool. The UCB has a specialized layout that
supports mailbox operations. The UCB maintains queues. There is a message queue
for messages written to the mailbox. There is a reader queue that tracks read
I/O requests to the mailbox. The data structures queued to reader queue are
called I/O Requests Packets (IRPs).
The UCB also
maintains queues to allow processes to be notified of unsolicited read or write
operations (read with no pending write or write with no pending read).
Processes are notified of these events through the delivery of an Asynchronous
System Trap (AST), known as an attention
AST. A similar attention AST can be delivered when space becomes available
in a full mailbox.
There are also queues
that allow your process to be notified when a new read or write channel is
assigned to a mailbox.
The point of this
discussion is that when you create a mailbox, regardless of how you size it,
you are only creating the UCB for the mailbox. The sizing parameters limit the
use of non-paged pool space to describe messages that are queued to the UCB.
So, a more accurate view of a mailbox with three write requests and no current
read looks like figure 3. The
"MBOX" headers describe the layout of the message block. These symbolic
offsets may not be available in earlier versions of OpenVMS. A view of a
mailbox with no active writes and one read looks like figure 4.
Figure 3. Mailbox with three Pending Writes
Figure 4. Mailbox with one Pending Read
When a mailbox is
created, the third argument to sys$crembx is the maximum message size and the
fourth argument is the mailbox buffer quota. The maximum message size restricts
the size of an individual message that can be written to the mailbox. This
setting can be used to set the size of the input buffer by the reader. If this
size is not specified, it is set by the system parameter DEFMBXMXMSG. On the
CREATE/MAILBOX command, the /MESSAGE_SIZE qualifier specifies the maximum
message size.
The buffer quota is
effectively the "size" of the mailbox. It is the maximum number of
bytes that can be written to the mailbox. Setting a large buffer quota does not
cause any space to be allocated from non-paged pool. What it does do, is allow
that many bytes to be potentially allocated from non-paged pool to support
mailbox writes. When an attempted write would cause a given mailbox to exceed
its buffer quota, the mailbox is considered full and the write will either
stall or fail. On the CREATE/MAILBOX command, the BUFFER_SIZE qualifier
specifies the mailbox size.
If the buffer quota
is not specified on the call to the sys$crembx system service, the setting for
the system parameter DEFMBXBUFQUO is used to size the mailbox. The maximum
advertised setting for this parameter is 64,000 bytes. You can override checks
in SYSGEN and set the parameter to a higher setting, if you are running V7.3-1
or greater. This should be done with great caution, as it will affect the
default size of all mailboxes that do not specify a non-zero buffer quota
parameter on a call to sys$crembx. You can alternatively, and more safely, set
a buffer quota parameter larger than 64,000 bytes as a buffer quota parameter
on mailbox creation for select mailboxes.
The key thing to keep
in mind when setting larger buffer quota settings is that you do not exhaust
non-paged pool. If you are going with higher settings for buffer quotas,
compensate with correspondingly larger settings for the system parameters
NPAGEDYN and NPAGEVIR.
You can monitor
mailbox space usage using the IO$_SENSEMODE function to the sys$qio system service.
This function receives no function dependent parameters (P1-P6). It returns the
number of messages queued to the mailbox in the iosb$w_bcnt field of the I/O
status block. It returns the number of message buffer bytes in the
iosb$l_dev_depend field of the I/O status block. You can obtain the buffer
quota and remaining buffer using the DVI$_MAILBOX_INITIAL_QUOTA and
DVI$_MAILBOX_QUOTA items through the sys$getdvi system service. Example 4 shows
a program that obtains and displays information on mailbox usage. There is a
sample SDA extension in the
SYS$EXAMPLES
directory, named MBX$SDA.C, that you can build and obtain more complete
information on all mailboxes on the system. We will discuss troubleshooting
full mailboxes later in this article.
Example 4. Sample Program to Monitor Mailbox Usage
The following program is implemented as a foreign command. It accepts a mailbox name
and displays the number of outstanding messages queued to the mailbox, the bytes in
use, bytes available, and mailbox size.
$ type mbx_usage.c
// Sample program to display total and available mailbox space.
// Implemented as a foreign command. Mailbox name is passed in on the command
// line
// Author: Bruce Ellis, BRUDEN-OSSG
#include
#include
#include
#include
#include
#include
#include
#include
#include
#include
#define check(S) if(!((S)&1)) sys$exit(S)
#define MBX 1
#define EXPECTED_ARGS 2
int main(int argc, char **args)
{
struct dsc$descriptor_s mbx_name;
unsigned int mbx_size;
unsigned int mbx_avail;
ile3 dvi_list[] = {{sizeof(mbx_size),DVI$_MAILBOX_INITIAL_QUOTA,
&mbx_size},
{sizeof(mbx_avail),DVI$_MAILBOX_BUFFER_QUOTA,
&mbx_avail}, {0,0}};
iosb ios;
int status;
short chan;
// If we do not have a mailbox name, exit
if(argc != EXPECTED_ARGS)
{
sys$exit(SS$_NOSUCHDEV);
}
// Set up mailbox name descriptor
mbx_name.dsc$w_length = strlen(args[MBX]);
mbx_name.dsc$a_pointer = args[MBX];
// Get mailbox information
status = sys$getdvi(EFN$C_ENF,0,&mbx_name,dvi_list,&ios,0,0,0,0);
check(status);
check(ios.iosb$w_status);
// Get more information from QIO
status = sys$assign(&mbx_name,&chan,0,0,0);
check(status);
status = sys$qiow(0,chan,IO$_SENSEMODE,&ios,0,0,0,0,0,0,0,0);
check(status);
check(ios.iosb$w_status);
// Display info.
printf("Mailbox size: %d\nRemaining bytes in mailbox: %d\n",
mbx_size,mbx_avail);
printf("Number of messages in the mailbox: %hd\nNumber of message bytes: %d\n",
ios.iosb$w_bcnt, ios.iosb$l_dev_depend);
return(SS$_NORMAL);
}
$
Compile and link the program.
$ cc mbx_usage
$ link mbx_usage
Setup a foreign command symbol to run the program.
$ mbu== "$sys$login:mbx_usage"
View a sample mailbox.
$ mbu MBA28605
Mailbox size: 100000
Remaining bytes in mailbox: 100000
Number of messages in the mailbox: 0
Number of message bytes: 0
$
Find OPCOM. Note: OPCOM reads from the mailbox MBA2:
$ show system/process=opcom
OpenVMS V8.3 on node ALPH40 18-NOV-2006 21:49:01.13 Uptime 55 02:47:35
Pid Process Name State Pri I/O CPU Page flts Pages
20400410 OPCOM HIB 8 406 0 00:00:00.24 688 43
No current activity on MBA2:
$ mbu MBA2
Mailbox size: 65535
Remaining bytes in mailbox: 65535
Number of messages in the mailbox: 0
Number of message bytes: 0
Suspend OPCOM.
$ set process/suspend/id=20400410
Send some data to MBA2:
$ spawn/nowait request "Please service this request!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!"
%DCL-S-SPAWNED, process ELLIS_14466 spawned
$ spawn/nowait request "Please service this request!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!"
%DCL-S-SPAWNED, process ELLIS_28545 spawned
$ spawn/nowait request "Please service this request!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!"
%DCL-S-SPAWNED, process ELLIS_19638 spawned
$ spawn/nowait request "Please service this request!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!"
%DCL-S-SPAWNED, process ELLIS_16419 spawned
$ spawn/nowait request "Please service this request!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!"
%DCL-S-SPAWNED, process ELLIS_48996 spawned
View OPCOM's mailbox. Note, the activity.
$ mbu MBA2
Mailbox size: 65535
Remaining bytes in mailbox: 64907
The number of messages queued seems to be off by 1. Note: a user mode AST has been
queued to OPCOM to service the completion of the first request. The AST could not
be delivered because OPCOM was suspended. Therefore, the first message has been
pulled from the queue to be serviced, dropping the message count by 1.
Number of messages in the mailbox: 4
Number of message bytes: 628
$
Resume OPCOM and clean out the mailbox.
$ set process/resume /id=20400410
$ mbu MBA2
Mailbox size: 65535
Remaining bytes in mailbox: 65535
Number of messages in the mailbox: 0
Number of message bytes: 0
$
|
|
|
|
|
|
|
As we mentioned
earlier, mailboxes can be read and written using high-level language
constructs, but are more commonly read and written using sys$qio system service
calls. If you are not familiar with
programming calls to sys$qio, you should invest some time reading the OpenVMS Programming Concepts Manual. Common
mistakes that beginners make when coding sys$qio calls include:
·
Using
a call to sys$qio, instead of using sys$qiow. The sys$qiow has an implicit wait
until the call has been serviced. Using
sys$qio calls work fine, as long as you implement waits at some point in your
program, usually through a call to sys$synch. With no explicit or implicit
waits, messages are queued up to the mailbox, causing it to fill and the
application to hang.
·
Not
passing and checking the I/O status block (IOSB) parameter. Status returned on
the call to sys$qio indicates whether the call was issued properly. It does not indicate whether the I/O request
completed properly. Completion status is returned in the low word of the IOSB structure.
This is described in the synchronization section of the OpenVMS Programming
Concepts Manual.
|
|
|
|
|
|
Mailboxes are read
through sys$qio using one of the function codes: IO$_READVBLK, IO$_READLBLK, or
IO$_READPBLK. For mailboxes, there is no difference between the function codes.
The sys$qio system service provides a uniform interface to all devices. Other devices will give different meaning to
the three functions within the context of the device.
When using one of the
read functions, the input buffer is passed by address in the P1 parameter to
sys$qio. The size of the buffer is passed in the P2 parameter. The size should
allow for the maximum message size allowed for the mailbox. If the message size
allowed on a read is smaller than the amount of data written, a status of
SS$_BUFFEROVF is returned in the IOSB status field. The data beyond the end of
the buffer is lost.
The actual number of
bytes written to the mailbox may be less than the size of the read buffer. The
actual number of bytes written to the mailbox is returned in the iosb$w_bcnt
field of the IOSB.
If the data in
message buffers is larger than you are anticipating in the input buffer, you
can preserve the data in the message buffer using the function modifier
IO$M_STREAM on the read. Subsequent reads will pick up the remnant data in the
message buffer.
When a read is posted
on a mailbox, it will not complete until a corresponding write is issued. This
can cause the application to hang if there is no current writer. In many cases,
this behavior is fine and desired. In cases where the writer may have failed,
this behavior may cause functional problems in the application. There are
several ways to deal with this potential problem, including:
- Using
the function modifier IO$M_NOW with a read function. If there are no pending
writes, the read will complete immediately with a zero byte read. In my
opinion, this is usually an undesirable option. It causes convoluted and
potentially poor performing code.
- Using
the function modifier IO$M_WRITERCHECK with a read function. This request will
return a status of SS$_NOWRITER if there is no data in the mailbox and there
are no write channels assigned to the mailbox. This option only works if the
channel assigned by the process using it was assigned as a read-only channel. A
variation of this method can be implemented using IO$M_WRITERCHECK with an
IO$_SENSEMODE function.
- Using
the function modifier IO$M_WRITERWAIT with the IO$_SETMODE function. The event flag set can be checked or an AST can
be delivered to the process notifying it that there is a write channel
assigned. As in the last bullet, this method only works with unidirectional
mailboxes.
- Using
a sys$setimr and an asynchronous sys$qio, then waiting for a "logical or"
of the event flags. You can use the sys$readef system service to determine
whether the timer expired or the read completed first and then process
accordingly.
To determine whether
a writer has completed a multi-write transmission, the cooperating processes
can use the IO$_WRITEOF function in the context of the writer, and the reader
can check for a status of SS$_ENDOFFILE in the IOSB.
On a read function,
the device dependent field of the IOSB contains the process identification
(PID) of the writer, unless the writer is a system process.
DCL READ commands
issued on mailboxes will read their contents and store them in symbols. Be
cautious of performing READ (and WRITE) commands interactively. They block
execution of the supervisor mode control Y AST.
|
|
|
|
|
|
Mailboxes can be
written using the sys$qio function codes IO$_WRITEVBLK, IO$_WRITELBLK, or
IO$_WRITEPBLK. Just as on writes, these function codes have identical meanings.
The write functions support a IO$M_READERCHECK function modifier that operates
in similar fashion to the IO$M_WRITERCHECK on read functions.
Simple mailbox writes
do not complete until a corresponding mailbox read is issued. A write to a
mailbox can be forced to complete using the function modifier IO$M_NOW. A message written with this function modifier
will be queued to a mailbox and control will be returned to the writer. As long
as the mailbox is not deleted, the message will stay in the mailbox until it is
read. You need to take caution that some process has a channel assigned to a temporary
mailbox, or the mailbox will be deleted when the writer program runs down.
The IO$M_NOW function
modifier should be used with care to prevent possibly filling the mailbox.
To notify the reader
that we are done transmitting data, you can send an "end of file" by
using the IO$_WRITEOF function code. The only effect of using this function is
that a status value of SS$_ENDOFFILE is returned to the reader's IOSB. This
technique is an optional method to signal that one stream of data is complete.
The reader could terminate on detection of this status or could start
processing another stream.
On a write function,
the device dependent field of the IOSB contains the PID of the reader of the
mailbox, except when the function modifier IO$M_NOW is used. In this case, the
field contains 0, as the mailbox has not necessarily been read by the time the
write completes.
The DCL WRITE command
can be used to write to a mailbox. The qualifier /NOWAIT implements the
function modifier IO$M_NOW on a WRITE.
When you issue a
close on a DCL-created mailbox, there is effectively an IO$_WRITEOF function
performed.
|
|
|
|
|
|
At this point, it
would probably be good to take a look at a couple of simple examples that use
mailboxes for communication. Example 5 illustrates a simple mailbox writer
program. The program reads strings from sys$input and sends them to the mailbox
named DATA_MBX. When an end of file is read from sys$input, a sys$qio is issued
with a function of IO$_WRITEOF. Example 6 illustrates a simple mailbox reader
program. The program reads from the data mailbox and sends output to sys$output
until a write using the function code IO$_WRITEOF is detected. Example 6a is a
DCL version of examples 5 and 6.
The logical name
LNM$TEMPORARY_MAILBOX is assigned to the logical name LNM$GROUP in user mode.
This practice allows the programs to be run from two different interactive
sessions. Sample runs of the programs are shown in each example. Note: the runs from the writer were run in
parallel with the reader.
Example 5. Simple Sample Mailbox Writer
$ type mailbox_writer.c
/*
Simple mailbox writer. Reads lines from standard input until
EOF and sends to a mailbox named DATA_MBX.
Author: Bruce Ellis, BRUDEN-OSSG
*/
#include
#include
#include
#include
#include
#include
#include
#include
#include
#include
#define MBX_PROT 0xF000
#define MAX_MSG 1024
#define BUF_QUO 60000
#define LIST_END 0
#define check(S) if(!((S)&1)) sys$exit(S)
int main(void)
{
iosb ios;
int status;
$DESCRIPTOR(ptable,"LNM$PROCESS_DIRECTORY");
$DESCRIPTOR(lnm,"LNM$TEMPORARY_MAILBOX");
char equiv[ ] = "LNM$GROUP";
ile3 lnm_items[ ] = {{strlen(equiv),LNM$_STRING,equiv},{LIST_END}};
$DESCRIPTOR(mbx,"DATA_MBX");
short chan;
int efn;
char in_buffer[BUFSIZ];
/* Create a logical name to allow the next temporary mailbox's name
we create to be placed in the group logical name table.
*/
status = sys$crelnm(0,&ptable,&lnm,0,lnm_items);
check(status);
/* Create/assign a channel to the data mailbox. */
status = sys$crembx(0,&chan,MAX_MSG,BUF_QUO,MBX_PROT,0,&mbx,0,0);
check(status);
/* Get an available event flag number. */
status = lib$get_ef(&efn);
check(status);
/* Read from standard input and send to mailbox until EOF. */
while(gets(in_buffer))
{
/* If input buffer is too large, abort. */
if(strlen(in_buffer)>MAX_MSG)
{
sys$exit(SS$_BUFFEROVF);
}
status = sys$qiow(efn,chan,IO$_WRITEVBLK,&ios,0,0,
in_buffer,strlen(in_buffer),0,0,0,0);
check(status);
check(ios.iosb$w_status);
}
/* Send an EOF to the mailbox. */
status = sys$qiow(efn,chan,IO$_WRITEOF,&ios,0,0,
0,0,0,0,0,0);
check(status);
check(ios.iosb$w_status);
return(SS$_NORMAL);
}
$
$ cc mailbox_writer
$ link mailbox_writer
$ r mailbox_writer
Bruce Ellis was here
Welcome to Mailboxes from BRUDEN-OSSG
We have lot's of great guys and a great Guy on board.
Control-Z was entered on the next line.
Exit
$
|
Example 6. Simple Sample Mailbox Reader
$ type mailbox_reader.c
/*
Example of a simple mailbox reader.
The program reads from a mailbox named DATA_MBX and
displays the data on sys$output until the writer issues
an IO$_WRITEOF function.
Author: Bruce Ellis, BRUDEN-OSSG
*/
#include
#include
#include
#include
#include
#include
#include
#include
#include
#include
#define MBX_PROT 0xF000
#define MAX_MSG 1024
#define BUF_QUO 60000
#define LIST_END 0
#define check(S) if(!((S)&1)) sys$exit(S)
int main(void)
{
iosb ios;
int status;
$DESCRIPTOR(ptable,"LNM$PROCESS_DIRECTORY");
$DESCRIPTOR(lnm,"LNM$TEMPORARY_MAILBOX");
char equiv[ ] = "LNM$GROUP";
ile3 lnm_items[ ] = {{strlen(equiv),LNM$_STRING,equiv},{LIST_END}};
$DESCRIPTOR(mbx,"DATA_MBX");
short chan;
char buffer[MAX_MSG + 1];
int efn;
int i;
/* Create a logical name to allow the next temporary mailbox's name
we create to be placed in the group logical name table.
*/
status = sys$crelnm(0,&ptable,&lnm,0,lnm_items);
check(status);
/* Create/assign a channel to the listener mailbox. */
status = sys$crembx(0,&chan,MAX_MSG,BUF_QUO,MBX_PROT,0,&mbx,0,0);
check(status);
/* Get an available event flag number. */
status = lib$get_ef(&efn);
check(status);
i=1;
/* Read and display until EOF. */
do
{
status = sys$qiow(efn,chan,IO$_READVBLK,&ios,0,0,
buffer,MAX_MSG,0,0,0,0);
check(status);
if(ios.iosb$w_status != SS$_ENDOFFILE)
{
check(ios.iosb$w_status);
buffer[ios.iosb$w_bcnt] = '\0';
printf("Message %08d: %s\n",i,buffer);
i++;
}
} while(ios.iosb$w_status != SS$_ENDOFFILE);
return(SS$_NORMAL);
}
$
$ cc mailbox_reader
$ link mailbox_reader
$ show logical data_mbx
"DATA_MBX" = "MBA29808:" (LNM$GROUP_000042)
$ show device data_mbx/full
Device MBA29808:, device type local memory mailbox, is online, record-oriented
device, shareable, mailbox device.
Error count 0 Operations completed 0
Owner process "" Owner UIC [JAVA,ELLIS]
Owner process ID 00000000 Dev Prot S:RWPL,O:RWPL,G:RWPL,W
Reference count 1 Default buffer size 1024
$
$ r mailbox_reader
Message 00000001: Bruce Ellis was here
Message 00000002: Welcome to Mailboxes from BRUDEN-OSSG
Message 00000003: We have lot's of great guys and a great Guy on board.
$
|
|
|
|
|
|
|
$
This is from session 1.
$
$ type temp_talker.com
$ on error then goto done
$ on control_y then goto done
$ !
$ !Create the logical name in the group logical name table.
$ define/table=lnm$process_directory lnm$temporary_mailbox lnm$group
$
$ ! create the temporary mailbox
$ create/mailbox/log bru_mbx
$
$ !Go back to standard temporary mailbox logical names
$ define/table=lnm$process_directory lnm$temporary_mailbox lnm$group
$
$ !Open the mailbox for write
$ open/write bmbx bru_mbx
$
$ !Read from the keyboard and send to the mailbox until EOF
$ read_loop:
$ read/prompt="Message: "/end=done sys$command record
$ write/now bmbx record
$ goto read_loop
$ done:
$
$ close bmbx
$
$
$ @temp_talker
%CREATE-I-CREATED, MBA33594: created
%DCL-I-SUPERSEDE, previous value of LNM$TEMPORARY_MAILBOX has been superseded
Message: Bruce Ellis was here
Message: We would not have CREATE/MAILBOX
Message: without a wonderful "Guy" at
Message: BRUDEN-OSSG
Control-Z entered here.
Message: *EXIT*
$
The logical name and device name are still there.
$ show logical bru_mbx
"BRU_MBX" = "MBA33594:" (LNM$GROUP_000042)
$ show device mba33594
Device Device Error
Name Status Count
MBA33594: Online 0
$
$ deas_mbx==" $ SYS$SYSDEVICE:[ELLIS]DEAS_DCL_MBX_CHAN"
$ deas_mbx bru_mbx !This feature is not currently available.
The mailbox does not go away until ALL channels are deassigned.
$ show device mba33594
Device Device Error
Name Status Count
MBA33594: Online 0
$
This is after the next session did the deassign.
$ show logical bru_mbx
%SHOW-S-NOTRAN, no translation for logical name BRU_MBX
$ show device mba33594
%SYSTEM-W-NOSUCHDEV, no such device available
$
*********************************************************
This is from a separate session.
$ type temp_listener.com
$
$ on error then goto done
$ on control_y then goto done
$ !
$ !Create the logical name in the group logical name table.
$ define/table=lnm$process_directory lnm$temporary_mailbox lnm$group
$
$ ! create the temporary mailbox
$ create/mailbox/log bru_mbx
$
$ !Go back to standard temporary mailbox logical names
$ define/table=lnm$process_directory lnm$temporary_mailbox lnm$group
$
$ i=1
$ !Open the mailbox and read and echo until end of file
$ open/read bmbx bru_mbx
$ read_loop:
$ read/end=done bmbx record
$ write sys$output f$fao("Message !8ZL: !AS",i,record)
$ goto read_loop
$ done:
$ close bmbx
$
$ @temp_listener
%CREATE-I-CREATED, MBA33594: created
%DCL-I-SUPERSEDE, previous value of LNM$TEMPORARY_MAILBOX has been superseded
Message 00000001: Bruce Ellis was here
Message 00000001: We would not have CREATE/MAILBOX
Message 00000001: without a wonderful "Guy" at
Message 00000001: BRUDEN-OSSG
$
$
$ deas_mbx==" $ SYS$SYSDEVICE:[ELLIS]DEAS_DCL_MBX_CHAN"
$
$ show logical bru_mbx
"BRU_MBX" = "MBA33594:" (LNM$GROUP_000042)
$ show device bru_mbx
Device Device Error
Name Status Count
MBA33594: Online 0
$
$ deas_mbx bru_mbx !This feature is not currently available.
$ show logical bru_mbx
%SHOW-S-NOTRAN, no translation for logical name BRU_MBX
$ show device MBA33594:
%SYSTEM-W-NOSUCHDEV, no such device available
$
|
Example 7 provides a
variation on the mailbox reader that uses the IO$M_STREAM function modifier on
input. The same writer as example 5 was used in the sample run, with the same
output provided.
Example 7.
Sample Streaming Reads
$ type mailbox_streamer.c
/*
Example of a simple mailbox reader.
The program reads from a mailbox named DATA_MBX and
displays the data on sys$output until the writer issues
an IO$_WRITEOF function.
Author: Bruce Ellis, BRUDEN-OSSG
*/
#include
#include
#include
#include
#include
#include
#include
#include
#include
#include
#define MBX_PROT 0xF000
#define MAX_MSG 1024
#define BUF_QUO 60000
#define LIST_END 0
#define check(S) if(!((S)&1)) sys$exit(S)
Force 10 byte reads.
#define READ_SIZE 10
int main(void)
{
iosb ios;
int status;
$DESCRIPTOR(ptable,"LNM$PROCESS_DIRECTORY");
$DESCRIPTOR(lnm,"LNM$TEMPORARY_MAILBOX");
char equiv[ ] = "LNM$GROUP";
ile3 lnm_items[ ] = {{strlen(equiv),LNM$_STRING,equiv},{LIST_END}};
$DESCRIPTOR(mbx,"DATA_MBX");
short chan;
char buffer[MAX_MSG + 1];
int efn;
int i;
/* Create a logical name to allow the next temporary mailbox's name
we create to be placed in the group logical name table.
*/
status = sys$crelnm(0,&ptable,&lnm,0,lnm_items);
check(status);
/* Create/assign a channel to the listener mailbox. */
status = sys$crembx(0,&chan,MAX_MSG,BUF_QUO,MBX_PROT,0,&mbx,0,0);
check(status);
/* Get an available event flag number. */
status = lib$get_ef(&efn);
check(status);
i=1;
/* Read and display until EOF. */
do
{
Allow the data to be streamed.
status = sys$qiow(efn,chan,IO$_READVBLK|IO$M_STREAM,&ios,0,0,
buffer,READ_SIZE,0,0,0,0);
check(status);
if(ios.iosb$w_status != SS$_ENDOFFILE)
{
check(ios.iosb$w_status);
buffer[ios.iosb$w_bcnt] = '\0';
printf("Message %08d: %s\n",i,buffer);
i++;
}
} while(ios.iosb$w_status != SS$_ENDOFFILE);
return(SS$_NORMAL);
}
$
$ cc mailbox_streamer
$ link mailbox_streamer
The MAILBOX_WRITER program was run at the same time as the mailbox
streamer. The same data was entered when the program ran.
$ r mailbox_streamer
Note: each line is truncated at 10 bytes, but no data is lost.
Message 00000001: Bruce Elli
Message 00000002: s was here
Message 00000003: Welcome to
Message 00000004: Mailboxes
Message 00000005: from BRUD
Message 00000006: EN-OSSG
Message 00000007: We have lo
Message 00000008: t's of gre
Message 00000009: at guys an
Message 00000010: d a great
Message 00000011: Guy on boa
Message 00000012: rd.
$
|
|
|
|
|
|
|
When a mailbox
becomes full, two different actions can occur. By default, processes attempting
to write to a full mailbox will stall in the RWMBX variation of MWAIT
state. It should be possible to delete
the process in current versions of OpenVMS. You may want, however, to
investigate the cause of the mailbox becoming full to prevent this behavior in
the future.
The hang is intended
to be a good behavior. The hope is that the mailbox will eventually be read and
the process will automatically be released from the stalled RWMBX scheduling
state. Indeed, a poorly designed mailbox reader that spends too much time
processing data before performing the next mailbox read can cause processes to
bounce in and out of RWMBX state. In this case, you would like to tune the
reader application. If this is not a possible action, you can consider
increasing the buffer quota (BUFQUO) setting on the mailbox.
However, the mailbox
reader may be stalled in an involuntary wait state, unable to read the mailbox.
It may also be the case that the reader has disappeared from the system
entirely, due to some internal failure in the application. Example 8 shows
processes stalled in RWMBX wait state.
Example 8. Sample RWMBX Wait States
$ show sys/sub
OpenVMS V8.3 on node ALPH40 19-NOV-2006 20:17:26.91 Uptime 56 01:15:55
Pid Process Name State Pri I/O CPU Page flts Pages
2040043B DTGREET LEF 4 814 0 00:00:01.44 590 692 S
20400D55 ELLIS_21769 RWAST 6 165 0 00:00:00.13 241 206 S
$ spawn/nowait r mbx_w
%DCL-S-SPAWNED, process ELLIS_35375 spawned
$ spawn/nowait r mbx_w
%DCL-S-SPAWNED, process ELLIS_36751 spawned
$ spawn/nowait r mbx_w
%DCL-S-SPAWNED, process ELLIS_37285 spawned
$ spawn/nowait r mbx_w
%DCL-S-SPAWNED, process ELLIS_27951 spawned
$ spawn/nowait r mbx_w
%DCL-S-SPAWNED, process ELLIS_57898 spawned
$ spawn/nowait r mbx_w
%DCL-S-SPAWNED, process ELLIS_36551 spawned
$ spawn/nowait r mbx_w
%DCL-S-SPAWNED, process ELLIS_19782 spawned
$ sh sys/sub
OpenVMS V8.3 on node ALPH40 19-NOV-2006 20:17:40.95 Uptime 56 01:16:09
Pid Process Name State Pri I/O CPU Page flts Pages
2040043B DTGREET LEF 4 814 0 00:00:01.44 590 692 S
20400D55 ELLIS_21769 RWAST 6 165 0 00:00:00.15 241 206 S
20400D8C ELLIS_35375 LEF 6 17 0 00:00:00.02 241 206 S
20400D8D ELLIS_36751 LEF 6 18 0 00:00:00.02 241 206 S
20400D8E ELLIS_37285 LEF 6 17 0 00:00:00.01 241 206 S
20400D8F ELLIS_27951 LEF 6 17 0 00:00:00.04 241 206 S
20400D90 ELLIS_57898 LEF 6 19 0 00:00:00.02 241 206 S
20400D91 ELLIS_36551 LEF 6 15 0 00:00:00.02 241 206 S
20400D92 ELLIS_19782 LEF 6 14 0 00:00:00.01 241 206 S
$ spawn/nowait r mbx_w
%DCL-S-SPAWNED, process ELLIS_32782 spawned
$ sh sys/sub
OpenVMS V8.3 on node ALPH40 19-NOV-2006 20:21:25.18 Uptime 56 01:19:53
Pid Process Name State Pri I/O CPU Page flts Pages
2040043B DTGREET LEF 4 814 0 00:00:01.44 590 692 S
20400D55 ELLIS_21769 RWAST 6 165 0 00:00:00.15 241 206 S
20400D8C ELLIS_35375 RWMBX 6 144 0 00:00:00.02 241 206 S
20400D8D ELLIS_36751 RWMBX 6 128 0 00:00:00.02 241 206 S
20400D8E ELLIS_37285 RWMBX 6 143 0 00:00:00.01 241 206 S
20400D8F ELLIS_27951 RWMBX 6 131 0 00:00:00.04 241 206 S
20400D90 ELLIS_57898 RWMBX 6 145 0 00:00:00.02 241 206 S
20400D91 ELLIS_36551 RWMBX 6 143 0 00:00:00.02 241 206 S
20400D92 ELLIS_19782 RWMBX 6 142 0 00:00:00.01 241 206 S
20400D93 ELLIS_32782 RWMBX 6 12 0 00:00:00.01 241 206 S
$
|
It may also be the
case that a race condition is entered under a heavy load, such that a system
that generally does not have processes stalling in RWAST state starts to see
this state show up. The ideal solution would be to locate the cause of the race
condition and correct it. In some cases, it is cheaper and faster to simply
increase the size of the mailbox (BUFQUO).
|
|
|
|
|
|
The two most common
problems associated with mailboxes are probably:
- Processes
stalling in RWMBX variation of MWAIT state due to a full mailbox.
- Processes
stalling in RWAST variation of MWAIT state due to exhaustion of buffered I/O
limit (BIOLM). This is most commonly caused by improper use of asynchronous
sys$qio calls.
In this article we
will address RWMBX issues.
When you find a
process in RWMBX state, you will likely first want to know which mailbox the
process is attempting to write. In the System Dump Analyzer (SDA) you can get
into the context of the target process by issuing a SET PROCESS command. If the
process has a channel assigned to one mailbox, the process is pretty
straightforward. You would just issue a
SHOW PROCESS/CHANNEL command.
If there are several
channels assigned, you will need to determine which channel is associated with
the call to sys$qio. Once in the context of the stalled process, you can view
the parameters passed to the sys$qio system service by examining registers. The
channel number of the device is passed as the second parameter. On HP
AlphaServer systems, you would examine register R17 to determine the second
parameter being passed to sys$qio. On an HP Integrity server system examine R33
to determine the second parameter passed to sys$qio. The contents of the
appropriate register will give you the channel number for the full mailbox that
the process is attempting to write.
You can next issue a
SHOW PROCESS/CHANNEL command to determine which channels are assigned by the
process. The full mailbox should have a channel number that matches the
hexadecimal value that you obtained from the register.
Once you know the
device name, you may want to map it to the logical name associated with the
mailbox. The UCB for the mailbox contains a pointer to the logical name
associated with the mailbox. You can format this address using a type of LNMB
(Logical Name Block).
See Example 9
(AlphaServer) or Example 10 (Itanium server) for an illustration of these
steps.
Example 9.
Locating the Channel Number for a Write to a Full Mailbox (Alpha)
View one of the processes in RWMBX state.
SDA> show summary/process=ELLIS_55216
Current process summary
-----------------------
Extended Indx Process name Username State Pri PCB/KTB PHD Wkset
-- PID -- ---- --------------- ------------ ------- --- -------- -------- ------
20400D9F 019F ELLIS_55216 ELLIS RWMBX 6 823D08C0 84B74000 206
Set context to the target process.
SDA> set process ELLIS_55216
Identify the channel associated with the QIO.
SDA> examine r17
R17: 00000000.000000D0 "Ð......."
Map the channel number to the mailbox device.
SDA> show process/channel
Process index: 019F Name: ELLIS_55216 Extended PID: 20400D9F
--------------------------------------------------------------------
Process active channels
-----------------------
Channel CCB Window Status Device/file accessed
------- --- ------ ------ --------------------
0010 7FF7C000 00000000 $1$DGA642:
0020 7FF7C020 8246F8C0 $1$DGA642:[ELLIS]MBX_W.EXE;7
0030 7FF7C040 81F5D500 $1$DGA642:[VMS$COMMON.SYSEXE]DCL.EXE;1 (section file)
0040 7FF7C060 00000000 TNA57:
0050 7FF7C080 00000000 TNA57:
0060 7FF7C0A0 81F4EA40 $1$DGA642:[VMS$COMMON.SYSLIB]DCLTABLES.EXE;775 (section file)
0070 7FF7C0C0 81F4ECC0 $1$DGA642:[VMS$COMMON.SYSLIB]LIBOTS.EXE;1 (section file)
0080 7FF7C0E0 81F53080 $1$DGA642:[VMS$COMMON.SYSLIB]DECC$SHR_EV56.EXE;1 (section file)
0090 7FF7C100 81F52900 $1$DGA642:[VMS$COMMON.SYSLIB]DPML$SHR.EXE;1 (section file)
00A0 7FF7C120 81F51140 $1$DGA642:[VMS$COMMON.SYSLIB]CMA$TIS_SHR.EXE;1 (section file)
00B0 7FF7C140 81F4EC40 $1$DGA642:[VMS$COMMON.SYSLIB]LIBRTL.EXE;1 (section file)
00C0 7FF7C160 00000000 TNA57:
00D0 7FF7C180 00000000 Busy MBA30202:
Total number of open channels : 13.
SDA>
View the mailbox I/O database information.
SDA> show device mba30202
I/O data structures
-------------------
MBA30202 MBX UCB: 821362C0
Device status: 88000010 online,exfunc_supp,iopost_local
Characteristics: 0C150001 rec,shr,avl,mbx,idv,odv
00000000
SUD Status 00000000
Owner UIC [000042,000042] Operation count 0 ORB address 823C7300
PID 00000000 Error count 0 DDB address 81853780
Class/Type A0/01 Reference count 10 DDT address 818E3740
Def. buf. size 256 BOFF 00000000 SUD address 8246F6C0
DEVDEPEND 0000037C Byte count 00000000 CRB address 818537F0
The logical name block address is in the "LNM address field".
DEVDEPND2 00000000 SVAPTE 00000000 LNM address 85322870
DEVDEPND3 00000000 DEVSTS 00000002 I/O wait queue 82136378
FLCK index 0B
DLCK address 824A7980
Charge PID 00030183
*** I/O request queue is empty ***
SDA> read sysdef
SDA> form 85322870/typ=lnmb
FFFFFFFF.85322870 LNMB$L_FLINK 850942B0
FFFFFFFF.85322874 LNMB$L_BLINK 853211D0
FFFFFFFF.85322878 LNMB$W_SIZE 0080
FFFFFFFF.8532287A LNMB$B_TYPE 40
FFFFFFFF.8532287B LNMB$B_PAD 00
FFFFFFFF.8532287C LNMB$L_ACMODE 00000003
FFFFFFFF.85322880 LNMB$L_TABLE 85322A08 LNM+00198
FFFFFFFF.85322884 LNMB$L_LNMX 853228A0 LNM+00030
FFFFFFFF.85322888 LNMB$L_FLAGS 00000000
LNMB$R_BITS
LNMB$R_FLAG_BITS
FFFFFFFF.8532288C LNMB$L_NAMELEN 00000009
FFFFFFFF.85322890 LNMB$T_NAME 42
View the mailbox logical name. The length of 9 identifies the characters for
the name. Everything beyond the first 9 characters, in this case, is garbage.
SDA> examine 85322890;9
30303430 325F4878 626D5F65 63757242 Bruce_mbxH_20400 FFFFFFFF.85322890
SDA>
|
Example 10.
Locating the Channel Number for a Write to a Full Mailbox (IA64)
View one of the processes in RWMBX state.
SDA> show summary/proc=ELLIS_56220
Current process summary
-----------------------
Extended Indx Process name Username State Pri PCB/KTB PHD Wkset
-- PID -- ---- --------------- ------------ ------- --- -------- -------- ------
218004C6 00C6 ELLIS_56220 ELLIS RWMBX 6 8555BF00 8C12C000 265
Set context to the target process.
SDA> set proc ELLIS_56220
Identify the channel associated with the QIO.
SDA> examine r33
R33: 00000000.000000D0 "Ð......."
SDA>
Map the channel number to the mailbox device.
SDA> show process/channel
Process index: 00C6 Name: ELLIS_56220 Extended PID: 218004C6
--------------------------------------------------------------------
Process active channels
-----------------------
Channel CCB Window Status Device/file accessed
------- --- ------ ------ --------------------
0010 7FF26000 00000000 $1$DGA242:
0020 7FF26020 8555CA80 $1$DGA242:[ELLIS]MBX_W.EXE;2
0030 7FF26040 853BC840 $1$DGA242:[VMS$COMMON.SYSEXE]DCL.EXE;1 (section file)
0040 7FF26060 00000000 TNA3:
0050 7FF26080 00000000 TNA3:
0060 7FF260A0 853AF9C0 $1$DGA242:[VMS$COMMON.SYSLIB]DCLTABLES.EXE;381 (section file)
0070 7FF260C0 853AFCC0 $1$DGA242:[VMS$COMMON.SYSLIB]LIBOTS.EXE;1 (section file)
0080 7FF260E0 853B4140 $1$DGA242:[VMS$COMMON.SYSLIB]DECC$SHR.EXE;1 (section file)
0090 7FF26100 853B37C0 $1$DGA242:[VMS$COMMON.SYSLIB]DPML$SHR.EXE;1 (section file)
00A0 7FF26120 853B2040 $1$DGA242:[VMS$COMMON.SYSLIB]CMA$TIS_SHR.EXE;1 (section file)
00B0 7FF26140 853AFB40 $1$DGA242:[VMS$COMMON.SYSLIB]LIBRTL.EXE;1 (section file)
00C0 7FF26160 00000000 TNA3:
00D0 7FF26180 00000000 Busy MBA6706:
Total number of open channels : 13.
SDA>
SDA>
View the mailbox I/O database information.
SDA> show device mba6706
I/O data structures
-------------------
MBA6706 MBX UCB: 85417E80
Device status: 88000010 online,exfunc_supp,iopost_local
Characteristics: 0C150001 rec,shr,avl,mbx,idv,odv
00000000
SUD Status 00000000
Owner UIC [000042,000042] Operation count 0 ORB address 8541E780
PID 00000000 Error count 0 DDB address 841ADB80
Class/Type A0/01 Reference count 10 DDT address 84248B40
Def. buf. size 256 BOFF 00000000 SUD address 85265280
DEVDEPEND 0000037C Byte count 00000000 CRB address 841ADBF0
The logical name block address is in the "LNM address field".
DEVDEPND2 00000000 SVAPTE 00000000 LNM address 8D1A65E0
DEVDEPND3 00000000 DEVSTS 00000002 I/O wait queue 85417FB0
FLCK index 0B
DLCK address 85519CC0
Charge PID 000100BC
*** I/O request queue is empty ***
SDA>
SDA> format 8D1A65E0/type=lnmb
FFFFFFFF.8D1A65E0 LNMB$L_FLINK 8CDCBCF0
FFFFFFFF.8D1A65E4 LNMB$L_BLINK 8D1A9EF0
FFFFFFFF.8D1A65E8 LNMB$W_SIZE 0070
FFFFFFFF.8D1A65EA LNMB$B_TYPE 40
FFFFFFFF.8D1A65EB LNMB$B_PAD 00
FFFFFFFF.8D1A65EC LNMB$L_ACMODE 00000003
FFFFFFFF.8D1A65F0 LNMB$L_TABLE 8D267A98
FFFFFFFF.8D1A65F4 LNMB$L_LNMX 8D1A6610 LNM+00030
FFFFFFFF.8D1A65F8 LNMB$L_FLAGS 00000000
LNMB$R_BITS
LNMB$R_FLAG_BITS
View the mailbox logical name. The length of 9 identifies the characters for
the name. Everything beyond the first 9 characters, in this case, is garbage.
FFFFFFFF.8D1A65FC LNMB$L_NAMELEN 00000009
FFFFFFFF.8D1A6600 LNMB$T_NAME 42
SDA> examine 8D1A6600;9
00000000 00000078 626D5F65 63757242 Bruce_mbx....... FFFFFFFF.8D1A6600
SDA>
|
The UCB for a mailbox
device has fields that are of specific interest when troubleshooting full
mailboxes. The first two longwords in a mailbox UCB (UCB$L_MB_MSGQFL / UCB$L_MB_MSGQBL)
contain the message queue forward and backward links. You can walk these links
and view the messages queued to the mailbox. The symbol table file SYSDEF.STB
contains MBOX symbol definitions that help you interpret these fields. These
symbol definitions are not available in older versions of OpenVMS.
Fields that track
read (UCB$L_MB_R_AST) and write (UCB$L_MB_W_AST) attention ASTs are after the
message queues and size and type fields. If the mailbox driver is currently
servicing an I/O request, the field UCB$L_IRP contains a pointer to the IRP.
Immediately after the
base UCB, the mailbox driver maintains:
- Counts
of read (UCB$L_MB_READERREFC ) and write (UCB$L_MB_WRITERREFC) channels that
have been assigned to the mailbox.
- A reader queue for outstanding reads that have been queued to the mailbox. (UCB$L_MB_READQFL/UCB$L_MB_READQBL)
- Queues
for mailbox waits for write/read channels to be assigned.
(UCB$L_MB_WRITERWAITQFL/UCB$L_MB_WRITERWAITQBL and
UCB$L_MB_READERWAITQFL/ UCB$L_MB_READERWAITQBL)
- Queues
for mailbox waits for all write/read channels to be deassigned. (UCB$L_MB_NOWRITERWAITQFL/UCB$L_MB_NOWRITERWAITQBL and UCB$L_MB_NOREADERWAITQFL/UCB$L_MB_NOREADERWAITQBL)
- A
list of ACBs for process notification that mailbox room is available. (UCB$L_MB_ROOM_NOTIFY)
- A
pointer to the logical name block for the mailbox. (UCB$L_LOGADR)
- The
available mailbox size. (UCB$L_MB_BUFQUO)
- The
initial mailbox size (Initial BUFQUO). (UCB$L_MB_INIQUO)
After you issue a SHOW
DEVICE command on the mailbox a symbol named UCB contains the address of the
UCB for the mailbox. To view relative elements on the message queue, you can
issue FORMAT @UCB commands. For each "@" character in the command you
move forward to that relative message, e.g., FORMAT @@@@UCB formats the fourth
message in the message queue. To determine the number of messages queued to the
mailbox, issue the command VALIDATE QUEUE UCB. Example 11 illustrates walking
the message queue for a given mailbox. The example works the same way on
AlphaServer and Integrity server systems.
Example 11.
Walking Mailbox Message Queues
View the first message on the message queue.
SDA> form @ucb
FFFFFFFF.854CFE80 MBOX_MSG$L_FLINK 8541FC80
MBOX_MSG$PS_ADDR
FFFFFFFF.854CFE84 MBOX_MSG$L_BLINK 85417E80 UCB
MBOX_MSG$PS_UVA32
FFFFFFFF.854CFE88 MBOX_MSG$W_MBZ 0000
FFFFFFFF.854CFE8A MBOX_MSG$B_TYPE 79
FFFFFFFF.854CFE8B MBOX_MSG$B_SUBTYPE 53
FFFFFFFF.854CFE8C MBOX_MSG$L_FUNCTION 00000020
FFFFFFFF.854CFE90 MBOX_MSG$PQ_UVA64 00000000.DEAD0001
FFFFFFFF.854CFE98 MBOX_MSG$L_SIZE 000000C0
FFFFFFFF.854CFE9C MBOX_MSG$L_IRP 85262E80
FFFFFFFF.854CFEA0 MBOX_MSG$L_NOREADERWAITQFL 00000000
FFFFFFFF.854CFEA4 MBOX_MSG$L_NOREADERWAITQBL 00000000
This is the internal process ID of the process that issued this message.
FFFFFFFF.854CFEA8 MBOX_MSG$L_PID 000100BEM SYS$K_VERSION_16+0007E
FFFFFFFF.854CFEAC MBOX_MSG$L_DATASTART 854CFEB8
FFFFFFFF.854CFEB0 MBOX_MSG$W_DATASIZE 0070
FFFFFFFF.854CFEB2 MBOX_MSG$W_BUFQUOCHARGE 0001
FFFFFFFF.854CFEB4 MBOX_MSG$L_THREAD_PID 218004BE
MBOX_MSG$C_LENGTH
Here is the message data.
FFFFFFFF.854CFEB8 MBOX_MSG$R_DATA 00005F53.494C4C45
SDA> examine 854CFEB8;70
65623430 30383132 00005F53 494C4C45 ELLIS_..218004be FFFFFFFF.854CFEB8
35383338 33323732 39303134 33303242 B203410927238385 FFFFFFFF.854CFEC8
39323930 33323936 37323330 35363936 6965032769230929 FFFFFFFF.854CFED8
33363534 31303532 37383732 39363138 8169278725014563 FFFFFFFF.854CFEE8
31383330 33363734 33323330 35383738 8785032347630381 FFFFFFFF.854CFEF8
35363138 35303730 31323930 33303734 4703092107058165 FFFFFFFF.854CFF08
31303136 33363734 33303134 39383738 8789410347636101 FFFFFFFF.854CFF18
SDA>
The next message in the queue.
SDA> form @@UCB
FFFFFFFF.8541FC80 MBOX_MSG$L_FLINK 854CE480
MBOX_MSG$PS_ADDR
FFFFFFFF.8541FC84 MBOX_MSG$L_BLINK 854CFE80
MBOX_MSG$PS_UVA32
FFFFFFFF.8541FC88 MBOX_MSG$W_MBZ 0000
FFFFFFFF.8541FC8A MBOX_MSG$B_TYPE 79
FFFFFFFF.8541FC8B MBOX_MSG$B_SUBTYPE 53
FFFFFFFF.8541FC8C MBOX_MSG$L_FUNCTION 00000020
FFFFFFFF.8541FC90 MBOX_MSG$PQ_UVA64 00000000.DEAD0001
FFFFFFFF.8541FC98 MBOX_MSG$L_SIZE 000000C0
FFFFFFFF.8541FC9C MBOX_MSG$L_IRP 85261E00
FFFFFFFF.8541FCA0 MBOX_MSG$L_NOREADERWAITQFL 00000000
FFFFFFFF.8541FCA4 MBOX_MSG$L_NOREADERWAITQBL 00000000
FFFFFFFF.8541FCA8 MBOX_MSG$L_PID 000100BF SYS$K_VERSION_16+0007F
FFFFFFFF.8541FCAC MBOX_MSG$L_DATASTART 8541FCB8
FFFFFFFF.8541FCB0 MBOX_MSG$W_DATASIZE 0070
FFFFFFFF.8541FCB2 MBOX_MSG$W_BUFQUOCHARGE 0001
FFFFFFFF.8541FCB4 MBOX_MSG$L_THREAD_PID 218004BF
MBOX_MSG$C_LENGTH
FFFFFFFF.8541FCB8 MBOX_MSG$R_DATA 00005F53.494C4C45
The third message...
SDA> form @@@UCB
FFFFFFFF.854CE480 MBOX_MSG$L_FLINK 854C9140
MBOX_MSG$PS_ADDR
FFFFFFFF.854CE484 MBOX_MSG$L_BLINK 8541FC80
MBOX_MSG$PS_UVA32
FFFFFFFF.854CE488 MBOX_MSG$W_MBZ 0000
FFFFFFFF.854CE48A MBOX_MSG$B_TYPE 79
FFFFFFFF.854CE48B MBOX_MSG$B_SUBTYPE 53
FFFFFFFF.854CE48C MBOX_MSG$L_FUNCTION 00000020
FFFFFFFF.854CE490 MBOX_MSG$PQ_UVA64 00000000.DEAD0001
FFFFFFFF.854CE498 MBOX_MSG$L_SIZE 000000C0
FFFFFFFF.854CE49C MBOX_MSG$L_IRP 854D1640
FFFFFFFF.854CE4A0 MBOX_MSG$L_NOREADERWAITQFL 00000000
FFFFFFFF.854CE4A4 MBOX_MSG$L_NOREADERWAITQBL 00000000
FFFFFFFF.854CE4A8 MBOX_MSG$L_PID 000100C0 SYS$K_VERSION_16+00080
FFFFFFFF.854CE4AC MBOX_MSG$L_DATASTART 854CE4B8
FFFFFFFF.854CE4B0 MBOX_MSG$W_DATASIZE 0070
FFFFFFFF.854CE4B2 MBOX_MSG$W_BUFQUOCHARGE 0001
FFFFFFFF.854CE4B4 MBOX_MSG$L_THREAD_PID 218004C0
MBOX_MSG$C_LENGTH
FFFFFFFF.854CE4B8 MBOX_MSG$R_DATA 00005F53.494C4C45
Determine the number of messages queued to the mailbox.
SDA> validate queue ucb
Queue is complete, total of 892 elements in the queue
SDA>
|
Once you have
determined how many messages are in the queue and which processes are sending
them, you will need to determine what happened to the mailbox reader. Is it
hung in a resource wait state? Has it encountered a race condition that caused
it to ignore the mailbox? Has the process died for some reason?
To identify where in
the code the process has stalled, you can view call frames and walk back to the
source of the call. Doing so requires that you have access to link maps and
machine code listings for the program that the hung process was running.
On HP AlphaServer
systems, the return address of the caller is stored in r26 when the sys$qio
code is entered. If a sys$qiow was called, that, in turn, made the call to
sys$qio; you will need to view call frames to locate the caller of sys$qiow.
Once you know the return PC, you can take it to the map file for the program
and find the program section that contains the given PC. You would then
subtract the base address of the containing program section to determine the
location counter for the machine code that contains the return address from the
call. The location counter can be taken to the listing file to locate the
machine code instruction for the return from the call.
From the return
instruction, you can back up one instruction at a time in the listing file,
looking for a source line number. In a 132 column display, the source line number
will be all the way to the right and will have a ";" prefix in front
of the source line number. This will get you to the source code and you can
determine what is happening in the context of the program. Example 12
illustrates mapping the call back to the source in the sys$qio case on an
AlphaServer system. Example 13 does the same for the sys$qiow case on an
AlphaServer system.
Example 12. Mapping the Return PC to Source for a Process
in RWMBX (sys$qio case on AlphaServer)
SDA> sh summary
Current process summary
-----------------------
Extended Indx Process name Username State Pri PCB/KTB PHD Wkset
-- PID -- ---- --------------- ------------ ------- --- -------- -------- ------
20400401 0001 SWAPPER SYSTEM HIB 16 818E5DC8 818E5800 0
20400407 0007 CLUSTER_SERVER SYSTEM HIB 13 81DEE600 84B2C000 113
...
2040043B 003B DTGREET SYSTEM LEF 4 81DB9640 84B2A000 692
204008B8 00B8 TCPIP$BOOTP_1 TCPIP$BOOTP LEF 10 8223D1C0 84B62000 280
20400DAD 01AD _TNA58: ELLIS CUR 002 6 8222F780 84B54000 659
20400DC5 01C5 ELLIS_14353 ELLIS RWMBX 6 822EFC40 84B32000 206
20400DC6 01C6 ELLIS_29302 ELLIS RWMBX 6 821D79C0 84B52000 206
20400DC7 01C7 ELLIS_7240 ELLIS RWMBX 6 822E8200 84B58000 206
20400DC8 01C8 ELLIS_61712 ELLIS RWMBX 6 821B1140 84B60000 206
20400DC9 01C9 ELLIS_31360 ELLIS RWMBX 6 821D6CC0 84B64000 206
20400DCA 01CA ELLIS_60365 ELLIS RWMBX 6 823D08C0 84B66000 210
SDA> set process/index=1c8
SDA> read/executive
View the call frames looking for a call to sys$qiow.
SDA> show call/summary
Call Frame Summary
------------------
There is no call frame for sys$qiow. Therefore, we will need to look for the
return PC in r26.
Frame Type Frame Address Return PC Procedure Entry
-------------------- ----------------- ----------------- -----------------
Stack Frame 00000000.7AE09990 00000000.00020064 00000000.000200A0 SYS$K_VERSION_08+00080
Stack Frame 00000000.7AE09AA0 FFFFFFFF.80385CE4 00000000.00020000 SYS$K_VERSION_06
Stack Frame 00000000.7AE09B30 00000000.7AF6C058 FFFFFFFF.80385B50 SYS$IMGSTA_C
Stack Frame 00000000.7AE09BB0 00000000.7AF6BE88 00000000.7AF6BE9C DCL+81E9C
Cannot display further call frames (Bottom of stack)
SDA> examine r26
This is the return PC.
R26: 00000000.000202A4 "¤......."
Verify that the instruction preceding the return PC is a jump to subroutine (JSR).
SDA> examine/inst 202a4-4
SYS$K_VERSION_08+00280: JSR R26,(R26)
SDA>
Determine the image that the process is running.
SDA> show summary/image/process= ELLIS_61712
Current process summary
-----------------------
Extended Indx Process name Username State Pri PCB/KTB PHD Wkset
-- PID -- ---- --------------- ------------ ------- --- -------- -------- ------
20400DC8 01C8 ELLIS_61712 ELLIS RWMBX 6 821B1140 84B60000 210
$1$DGA642:[ELLIS]MBX_W.EXE;9
SDA> EXIT
$
View the map file, looking for the program section containing the PC.
$ type mbx_w.map
19-NOV-2006 22:37 Linker A13-03 Page 1
+------------------------+
! Object Module Synopsis !
+------------------------+
Module Name Ident Bytes File Creation Date Creator
----------- ----- ----- ----- ------------- -------
MBX_W V1.0 2377 SYS$SYSDEVICE:[ELLIS]MBX_W.OBJ;7 19-NOV-2006 22:37 Compaq C V6.5-001
+--------------------------+
! Program Section Synopsis !
+--------------------------+
Psect Name Module Name Base End Length Align Attributes
---------- ----------- ---- --- ------ ----- ----------
$LINK$ 00010000 000101BF 000001C0 ( 448.) OCTA4 NOPIC,CON,REL,LCL,NOSHR,NOEXE,NOWRT,NOVEC, MOD
MBX_W 00010000 000101BF 000001C0 ( 448.) OCTA4
$LITERAL$ 000101C0 000101E4 00000025 ( 37.) OCTA4 PIC,CON,REL,LCL, SHR,NOEXE,NOWRT,NOVEC, MOD
MBX_W 000101C0 000101E4 00000025 ( 37.) OCTA4
$READONLY$ 000101F0 000101FF 00000010 ( 16.) OCTA4 PIC,CON,REL,LCL, SHR,NOEXE,NOWRT,NOVEC, MOD
MBX_W 000101F0 000101FF 00000010 ( 16.) OCTA4
CR_VALS 00010200 0001020F 00000010 ( 16.) OCTA4 NOPIC,OVR,REL,GBL,NOSHR,NOEXE,NOWRT,NOVEC, MOD
MBX_W 00010200 0001020F 00000010 ( 16.) OCTA4
Here is the Program Section containing the return PC. The base of the
program section is at 20000, so the offset into module MBX_W for the point of
the call is 202a0.
$CODE$ 00020000 0002072B 0000072C ( 1836.) OCTA4 PIC,CON,REL,LCL, SHR, EXE,NOWRT,NOVEC, MOD
MBX_W 00020000 0002072B 0000072C ( 1836.) OCTA4
$BSS$ 00030000 00030017 00000018 ( 24.) OCTA4 NOPIC,CON,REL,LCL,NOSHR,NOEXE, WRT,NOVEC,NOMOD
MBX_W 00030000 00030017 00000018 ( 24.) OCTA4
...
$ edit mbx_w.lis
First search for the location counter 000002a0. We find it below, then back to
the source line number.
D3400089 0258 BSR R26, GEN_BUFF ; 021837
Source line number 21835 should be the location that the call to sys$qio was
made.
A7420078 025C LDQ R26, 120(R2) ; 021835
47E41410 0260 MOV 32, R16
47E70411 0264 MOV R7, R17
47E61412 0268 MOV 48, R18
B41E0000 026C STQ R0, (SP)
47EE1400 0270 MOV 112, R0
B7FE0010 0274 STQ R31, 16(SP)
227D0028 0278 LDA R19, mb_ios ; R19, 40(FP)
B41E0008 027C STQ R0, 8(SP)
B7FE0018 0280 STQ R31, 24(SP)
47FF0414 0284 CLR R20
47FF0415 0288 CLR R21
B7FE0020 028C STQ R31, 32(SP)
B7FE0028 0290 STQ R31, 40(SP)
47E19419 0294 MOV 12, R2
A7620080 0298 LDQ R27, 128(R2)
2FFE0000 029C UNOP
6B5A4000 02A0 JSR R26, SYS$QIO ; R26, R26
A742FFA8 02A4 LDQ R26, -88(R2) ; 021838
F0000004 02A8 BLBS R0, L$21
47E00410 02AC MOV R0, status ; R0, R16 ; 021835
Now we search for the source line.
1 21823 /* Assign a channel to the mailbox. */
1 21824 status = sys$crembx(0,&mbx_chan,0,0,0,0,&mbx,0,0);
1 21825 check(status);
1 21826
1 21827 /* Write messages to the mailbox. */
1 21828 for(i=0;i<500;i++)
2 21829 {
2 21830
2 21831 stall = ten_ms * ((rand()%300)+1);
2 21832 status = sys$setimr(TEFN,&stall,0,0,0);
2 21833 check(status);
2 21834 sys$waitfr(TEFN);
Here is the point of the call.
2 21835 status = sys$qio(MEFN,mbx_chan,IO$_WRITEVBLK,
2 21836 &mb_ios,0,0,
2 21837 gen_buff(&mrec,&id,count++),sizeof(mrec),0,0,0,0);
2 21838 check(status);
2 21839 //check(mb_ios.iosb$w_status);
1 21840 }
1 21841 stall = ten_ms * 300*1000*100;
|
Example 13.
Locating the Return PC for a Process in RWMBX (sys$qiow case on
AlphaServer)
In this case, the call to sys$qiow does show up in the call frames. Once we
have the return PC, the steps are the same as in example 12.
SDA> set proc/index=1ca
SDA> show call/summary
Call Frame Summary
------------------
Frame Type Frame Address Return PC Procedure Entry
-------------------- ----------------- ----------------- -----------------
Stack Frame 00000000.7AE09930 00000000.000202A4 FFFFFFFF.80114BD0 SYS$QIOW_C
Stack Frame 00000000.7AE09990 00000000.00020064 00000000.000200A0 SYS$K_VERSION_08+00080
Stack Frame 00000000.7AE09AA0 FFFFFFFF.80385CE4 00000000.00020000 SYS$K_VERSION_06
Stack Frame 00000000.7AE09B30 00000000.7AF6C058 FFFFFFFF.80385B50 SYS$IMGSTA_C
Stack Frame 00000000.7AE09BB0 00000000.7AF6BE88 00000000.7AF6BE9C DCL+81E9C
Cannot display further call frames (Bottom of stack)
SDA>
|
Full mailboxes
should be rare in a well-designed application. Hopefully, the steps above will
help you out in the rare case that you need to troubleshoot an RWMBX hang.
|
|
|
|
|
|
For some, a picture is worth a thousand words. For others,
seeing code in a complete application helps clarify the concept. The following
example illustrates most of the concepts described in this article.
It is rare that an application uses mailboxes for the sole
purpose of doing mailbox communication. To illustrate operating asynchronously
in an OpenVMS environment, we designed a series of functions and programs to
sample the Program Counter, the Buffered and Direct I/O counts for any given
application. This data, along with a time stamp, will be logged to a file.
The data will be captured by an Asynchronous System Trap (AST)
routine that will be called based on timer expiration. The data we are
capturing could be used to profile the performance characteristics of any
application. This specific data is not as relevant as the design
considerations. Note that the same approach could be used to sample other forms
of real-time data.
This example illustrates:
- Requesting timers
- AST routines
- Local Event Flags
- The "I/O" status block
- Getting Job/Process information
- Obtaining a time stamp
- Using item list entries (ile3 structures)
- Processing Mailboxes
- Process creation
- Creating Mailboxes
- QIO Interface to the mailbox
From a design perspective, we attempt to maintain data
encapsulation through the use of structures that describe the context of
operations, such as samples, files, I/O, etc.
The structures are passed as parameters to procedures and
external/common storage is avoided. This method improves the ability to debug,
maintain, and extend the application.
We attempt to minimize "noise" and
"drift" in the main sampler process by creating a background process
that will:
- Create
a temporary mailbox for communication with the parent process.
- Create
the log file, whose name is passed from the parent process.
- Accept
samples from the mailbox and write them to the log file, until an EOF is sent
from the parent.
All mailbox I/O is processed asynchronously.
The file is synched in the background by the child process
and the drift is reduced on the samples.
You may want to be able to view the
data in real-time. The PC_LOGGER is designed to write the samples to a
"listener" mailbox. This mailbox can be read by a listener process
that may be logged in on another terminal session. The listener can then
display the data in real-time.
The listener process
will be logged in separately from the process in which the sampler is being
run. Therefore, the mailbox logical name presents a problem. Normally,
temporary mailbox names are entered into the job logical name table.
In the listener and
the logger the logical name LNM$TEMPORARY_MAILBOX is equated to LNM$GROUP to
make the mailbox logical name visible to other processes in the UIC group. The
logical name is placed in the logical name table LNM$PROCESS_DIRECTORY.
Since the logical
name is created in user mode, it goes away when the images run down, so as to
not impact other images run by this process.
It is important to
note that the logical name is created AFTER the logger mailbox is
created/channel assigned. So, the logger mailbox logical name still goes into
the job logical name table.
The listener mailbox
is implemented as write-only by the logger and read-only by the listener. This
method allows us to simply send the message to the mailbox from the logger. If
there is no reader (listener), the mailbox write completes immediately with a
status of SS$_NOREADER. When this status is received, we "shrug our
shoulders" and try again next time. Similarly, the listener will abort if
there is no writer.
When we are done
the application design looks like figure 5.
Figure 5. PC Sampler "System Design"
Example 14.
The PC_SAMPLER Header File
$ type pc_sampler2.h
#include
/*
Context for our PC sampler.
File pointer for where to write the data.
Delta time for our sampling interval.
*/
typedef struct pc_sample_ctx
{
__int64 delta;
int c_pid;
int sample_no;
short mbx_chan;
} Sample_ctx;
/* Profile data */
typedef struct sample_data
{
__int64 time_stamp;
int pc;
int bio;
int dio;
int sample_no;
} Samp;
#define CPU_TIMER 1
int init_sampler(Sample_ctx *,char *);
void sample_pc(Sample_ctx *, unsigned int, unsigned int,
unsigned int, unsigned int);
int cleanup_sampler(Sample_ctx *);
$
$
|
Example 15.
PC Sampler Test and Stub Programs
$ type pc_tester2.c
#include
#include
#include "pc_sampler2.h"
void stub(void);
int main(void)
{
int i;
Sample_ctx ctx;
init_sampler(&ctx,"sample.data");
for(i=0;i<1000000000;i++)
{
stub();
}
cleanup_sampler(&ctx);
}
$
$ type stub.c
void stub(void) {;}
$
|
Example 16.
PC Sampler Routines
$ type pc_sampler3.c
/* Set of routines to sample program counters at
1 second (CPU time) intervals and send the PC and time of
sample to a logger process created by this routine.
*/
#include "pc_sampler2.h"
#include
#include
#include
#include
#include
#include
#include
#include
#include
#include
#define JPI_LISTEND 0
#define check(S) if(!((S)&1)) sys$exit(S)
/* Flag to indicate that the sample is active. */
static int active = 0;
/* Sample interval is a constant 1 second. */
static const __int64 sample_interval = -10000000;
#define BASE_PRI 4
#define MBX_EFN 32
#define ACK_SIZE 4
#define TERM_MAX 255
/*
Initialize the PC Sampler:
1) Verify that the sampler is not active, before making it active
2) Set the initial timer.
3) Create a mailbox.
4) Create a child process to log messages.
*/
int init_sampler(Sample_ctx *context, char *fname)
{
int status;
$DESCRIPTOR(mbx_name,"PC_LOGGER_MBX");
$DESCRIPTOR(image,"PC_LOGGER2");
char ack_buffer[ACK_SIZE];
iosb ios;
char terminal[TERM_MAX+1];
$DESCRIPTOR(term,terminal);
ile3 term_list[] = {{TERM_MAX,JPI$_TERMINAL,terminal,
&term.dsc$w_length},{0,0}};
/* If the sampler is already active, return a failure status,
else make it active.
*/
if(!active)
{
active = 1;
}
else
{
fprintf(stderr,"Sampler is already active.\n");
}
/*
Create the mailbox for communications with the child.
*/
status = sys$crembx(0,&context->mbx_chan,0,0,0,0,&mbx_name,0,0);
check(status);
/* Call SYS$GETJPI to obtain our terminal name. */
status = sys$getjpiw(0,0,0,term_list,&ios,0,0);
check(status);
check(ios.iosb$w_status);
/* Create the child logger process. */
status = sys$creprc(&context->c_pid,&image,0,&term,&term,
0,0,&image,BASE_PRI,0,0,0,0,0,0);
check(status);
/* Send the file name to the child. */
status = sys$qiow(MBX_EFN,context->mbx_chan,IO$_WRITEVBLK,&ios,
0,0,fname,strlen(fname),0,0,0,0);
check(status);
check(ios.iosb$w_status);
/* Read the same mailbox for an acknowledgment that the file was created
properly.
*/
status = sys$qiow(MBX_EFN,context->mbx_chan,IO$_READVBLK,&ios,
0,0,ack_buffer,ACK_SIZE,0,0,0,0);
check(status);
check(ios.iosb$w_status);
ack_buffer[ios.iosb$w_bcnt] = '\0';
/* Make sure the child created the log file properly. If not, return
error.
*/
if(strcmp(ack_buffer,"ACK") != 0)
{
return(RMS$_FNF);
}
/* Save collection interval in context block. */
context->delta = sample_interval;
context->sample_no = 0;
/* Set a timer for collections. */
status = sys$setimr(0,&context->delta,sample_pc,context,CPU_TIMER);
check(status);
}
/**********************************
Sampler AST Routine.
1) Grabs the PC.
2) Writes the PC and a timestamp to collection log process
through mailbox.
3) Resets the timer.
**********************************/
void sample_pc(Sample_ctx *context,unsigned int r0,unsigned int r1,
unsigned int pc,unsigned int ps)
{
int wrt_cnt;
static Samp sample;
int status;
ile3 jpi_items[] = {
{sizeof(sample.bio),JPI$_BUFIO,
&sample.bio},
{sizeof(sample.dio),JPI$_DIRIO,
&sample.dio},
{0,JPI_LISTEND}
};
iosb ios;
/* Reset the timer. */
status = sys$setimr(0,&context->delta,sample_pc,context,CPU_TIMER);
check(status);
/* Save the sample PC. */
sample.pc = pc;
/* Obtain a timestamp. */
status = sys$gettim(&sample.time_stamp);
check(status);
/* Call SYS$GETJPI to obtain our buffered and direct I/O counts. */
status = sys$getjpiw(0,0,0,jpi_items,&ios,0,0);
check(status);
check(ios.iosb$w_status);
/* Update and copy the sample number. */
sample.sample_no = ++(context->sample_no);
/* Write our collection data to the log file. */
status = sys$qiow(MBX_EFN,context->mbx_chan,IO$_WRITEVBLK|IO$M_NOW,
&ios,0,0,
&sample,sizeof(sample),0,0,0,0);
check(status);
check(ios.iosb$w_status);
}
/**********************************
Cleanup the PC sampler by:
1) Cancelling the sampler timer.
2) Marking the sampler inactive.
3) Sending EOF status to the child.
**********************************/
int cleanup_sampler(Sample_ctx *context)
{
int status;
iosb ios;
/* Cancel the timer. */
status = sys$cantim(context,0);
check(status);
/* Notify the logger to close the file. */
status = sys$qiow(MBX_EFN,context->mbx_chan,IO$_WRITEOF,&ios,
0,0,0,0,0,0,0,0);
check(status);
check(ios.iosb$w_status);
/* Mark the sampler inactive. */
active = 0;
return(status);
}
$
|
Example 17.
PC_LOGGER Header File
Header file for the PC Sample logger.
$ type pc_logger.h
#include
#include "pc_sampler2.h"
typedef struct mbx_context
{
FILE *fp;
Samp *samp_buffer;
iosb ios;
short chan;
} Mbx_ctx;
$
|
Example 18. PC_LOGGER Code
$ type pc_logger2.c
/*
Program to accept PC_Sample data and write it
to a log file.
The logger will send the data to a listener.
*/
#include
#include
#include
#include
#include
#include
#include
#include
#include
#include "pc_logger2.h"
#include
#define check(S) if(!((S)&1)) sys$exit(S)
#define LIST_END 0
#define MAX_FNAME 255
void synch_ast(Mbx_ctx *);
void mbx_ast(Mbx_ctx *);
int main(void)
{
int status;
Mbx_ctx ctx;
Samp sample;
char fname[MAX_FNAME+1];
char nak[] = "NAK";
char ack[] = "ACK";
char *msg;
__int64 synch_time = (__int64) -50000000;
$DESCRIPTOR(mbx_name,"PC_LOGGER_MBX");
/* Descriptors to allow temporary mailbox names to be placed in the
group logical name table.
*/
$DESCRIPTOR(ptable,"LNM$PROCESS_DIRECTORY");
$DESCRIPTOR(lnm,"LNM$TEMPORARY_MAILBOX");
char equiv[ ] = "LNM$GROUP";
ile3 lnm_items[ ] = {{strlen(equiv),LNM$_STRING,equiv},{LIST_END}};
$DESCRIPTOR(l_mbx,"PC_LISTENER_MBX");
/* Create /assign a channel to a temporary mailbox for log data. */
status = sys$crembx(0,&ctx.chan,0,0,0,0,&mbx_name,0,0);
check(status);
/* Read the mailbox to determine the target (log) file name. */
status = sys$qiow(0,ctx.chan,IO$_READVBLK,&ctx.ios,0,0,
fname,MAX_FNAME,0,0,0,0);
check(status);
check(ctx.ios.iosb$w_status);
fname[ctx.ios.iosb$w_bcnt] = '\0';
/* Open/create the file. */
ctx.fp = fopen(fname,"w");
/* Send an ACK/NAK dependent on the creation status. */
if(!ctx.fp)
{
msg = nak;
}
else
{
msg = ack;
}
status = sys$qiow(0,ctx.chan,IO$_WRITEVBLK,&ctx.ios,0,0,
msg,strlen(msg),0,0,0,0);
check(status);
check(ctx.ios.iosb$w_status);
/* Create a logical name to allow the next temporary mailbox's name
we create to be placed in the group logical name table.
*/
status = sys$crelnm(0,&ptable,&lnm,0,lnm_items);
check(status);
/* Create/assign a channel to the listener mailbox. */
status = sys$crembx(0,&ctx.l_chan,0,0,0,0,&l_mbx,CMB$M_WRITEONLY,0);
check(status);
/* Set a timer for synching the file. */
status = sys$setimr(0,&synch_time,synch_ast,&ctx,0);
check(status);
/* set up shared context for the sample buffer. */
ctx.samp_buffer = &sample;
/* Post an asynchronous read to the mailbox. */
status = sys$qio(0,ctx.chan,IO$_READVBLK,&ctx.ios,mbx_ast,&ctx,
ctx.samp_buffer,sizeof(*(ctx.samp_buffer)),0,0,0,0);
check(status);
/* Go to sleep. */
sys$hiber();
/* If we are waken, run down. */
return(SS$_NORMAL);
}
/* AST routine to read the mailbox. */
#define EXP_OBJECTS_WRITTEN 1
void mbx_ast(Mbx_ctx *ctx)
{
int write_cnt;
int status;
/* Check to see if the qio completed properly. */
switch(ctx->ios.iosb$w_status)
{
case SS$_ENDOFFILE:
fclose(ctx->fp);
status = sys$wake(0,0);
check(status);
status = sys$cantim(0,0);
check(status);
/* Send EOF to listener. */
status = sys$qiow(0,ctx->l_chan,
IO$_WRITEOF|IO$M_READERCHECK,
&ctx->l_ios,0,0,
0,0,0,0,0,0);
check(status);
if(ctx->l_ios.iosb$w_status == SS$_NOREADER)
{
/* Ignore if no reader. */
;
}
else
{
check(ctx->l_ios.iosb$w_status);
}
break;
default:
check(ctx->ios.iosb$w_status);
write_cnt = fwrite(ctx->samp_buffer,
sizeof(*(ctx->samp_buffer)),
1,ctx->fp);
if(write_cnt != EXP_OBJECTS_WRITTEN)
{
fprintf(stderr,"Write error!\n");
}
/* Post another read to the mailbox. */
status = sys$qio(0,ctx->chan,IO$_READVBLK,
&ctx->ios,mbx_ast,ctx,
ctx->samp_buffer,
sizeof(*(ctx->samp_buffer)),0,0,0,0);
check(status);
/* Send buffer to listener. */
status = sys$qiow(0,ctx->l_chan,
IO$_WRITEVBLK|IO$M_READERCHECK,
&ctx->l_ios,0,0,
ctx->samp_buffer,
sizeof(*(ctx->samp_buffer)),0,0,0,0);
check(status);
if(ctx->l_ios.iosb$w_status == SS$_NOREADER)
{
/* Ignore if no reader. */
;
}
else
{
check(ctx->l_ios.iosb$w_status);
}
break;
}<
}
#include
/* AST routine to synch the file every 5 seconds. */
void synch_ast(Mbx_ctx *ctx)
{
__int64 synch_time = -50000000;
int status;
/* Synch the file. */
fsync(fileno(ctx->fp));
/* Reset a timer for synching the file. */
status = sys$setimr(0,&synch_time,synch_ast,ctx,0);
check(status);
}
$
|
Example 19.
Code to Dump Samples
This code is implemented as a foreign command.
$
$ type dump_samples.c
/*****************************************
Program to dump output from PC Sampler log file.
Foreign comand setup by using the DCL command:
$ PC_DUMP == "$dev[dir]DUMP_SAMPLES.EXE"
*****************************************/
#include
#include
#include // This is from SYS$LIBRARY:DECCRTLDEF.TLB
#include
#include
#include "pc_sampler1.h"
#define EXPECTED_ARGS 2
#define NO_ARGS 1
#define FILE_ARG 1
#define TIME_STR_LEN 23
#define LINES_PER_PAGE 24
#define CMD_ARG 1
#define check(S) if(!((S)&1)) sys$exit(S)
/* Get parameter(s) from the command line. */
int main(int argc, char **args)
{
/* File pointer for the data file. */
FILE *fp;
int i;
/* Structure for the sample data. */
Samp sample;
int items_read;
int status;
/* String to hold the text representation of the time stamp. */
char time_str[TIME_STR_LEN+1];
$DESCRIPTOR(time_dsc,time_str);
/* Process the command line argument(s). */
switch(argc)
{
default:
fprintf(stderr,"Bad command format!"
"\nUse: PC_DUMP file-name\n");
exit(SS$_INSFARG);
break;
case EXPECTED_ARGS:
/* Open the data file. */
fp = fopen(args[FILE_ARG],"r");
if(!fp)
{
fprintf(stderr,"Bad input file name.\n");
perror(args[CMD_ARG]);
exit(EXIT_FAILURE);
}
}
i = 0;
/* Read until EOF or error and display the samples. */
while((items_read = fread(&sample,sizeof(sample),1,fp)) == 1)
{
status = sys$asctim(&time_dsc.dsc$w_length,&time_dsc,
&sample.time_stamp,0);
check(status);
/* Convert the string returned to a C-style string. */
time_str[time_dsc.dsc$w_length] = '\0';
/* Print a header after each 24 lines. */
if(i%LINES_PER_PAGE == 0)
{
printf("%-8s %-23s %-8s %-10s %-10s\n",
"Sample","Time of Sample","PC","BIO","DIO");
printf("%-8s %-23s %-8s %-10s %-10s\n",
"------","--------------","--","---","---");
}
printf("%08d: %23s %08x %10d %-10d\n",
++i,time_str,sample.pc,sample.bio,sample.dio);
}
/* Make sure we hit the end of file. */
if(feof(fp))
{
puts("***** No more data *****");
}
else
{
fprintf(stderr,"Error reading %s\n",args[FILE_ARG]);
exit(EXIT_FAILURE);
}
return(EXIT_SUCCESS);
}
$
$
$ cc dump_samples
$ link dump_samples
$
Define a foreign command for the sample dumper.
$ pc_dump == "$SYS$SYSDEVICE:[ELLIS.NASA]dump_samples"
$
Validate that the code generates an error when no sample file name is provided.
$ pc_dump
Bad command format!
Use: PC_DUMP file-name
%SYSTEM-F-INSFARG, insufficient call arguments
$
|
Example 20. PC_LISTENER Code
$ type pc_listener.c
/*************************************
PC_LISTENER
listens to PC_LISTENER_MBX mailbox and displays samples.
If no PC_LOGGER is active, aborts
*************************************/
#include
#include
#include
#include
#include
#include
#include
#include
#include
#include
#define check(S) if(!((S)&1)) sys$exit(S)
#include "pc_sampler3.h"
#define TIME_STR_LEN 23
#define LIST_END 0
int main(void)
{
/* Mailbox name. */
$DESCRIPTOR(mbx,"PC_LISTENER_MBX");
int status;
iosb ios;
short chan;
__int64 stall = (__int64) -20000000;
Samp buffer;
/* String yo hold the text representation of the time stamp. */
char time_str[TIME_STR_LEN+1];
$DESCRIPTOR(time_dsc,time_str);
$DESCRIPTOR(ptable,"LNM$PROCESS_DIRECTORY");
$DESCRIPTOR(lnm,"LNM$TEMPORARY_MAILBOX");
char equiv[] = "LNM$GROUP";
ile3 lnm_items[] = {{strlen(equiv),LNM$_STRING,equiv},{LIST_END}};
/*
Create a logical name to cause the mailbox name to be placed
in the group logical name table.
*/
status = sys$crelnm(0,&ptable,&lnm,0,lnm_items);
check(status);
/* Create/assign a table to the mailbox. */
status = sys$crembx(0,&chan,0,0,0,0,&mbx,CMB$M_READONLY,0);
check(status);
/* Read the mailbox using SYS$QIO until EOF. */
do
{
status = sys$qiow(0,chan,IO$_READVBLK|IO$M_WRITERCHECK,&ios,
0,0,&buffer,sizeof(buffer),0,0,0,0);
check(status);
switch(ios.iosb$w_status)
{
case SS$_ENDOFFILE:
puts("*** No more Data *** ");
break;
case SS$_NOWRITER:
fprintf(stderr,"Logger is not active. "
"Try again later.\n");
sys$exit(SS$_NOLISTENER);
break;
default:
check(ios.iosb$w_status);
/* Send the message to the screen. */
status = sys$asctim(&time_dsc.dsc$w_length,
&time_dsc,
&buffer.time_stamp,0);
check(status);
/* Convert the time string returned to a C-style string. */
time_str[time_dsc.dsc$w_length] = '\0';
printf("%08d: %23s %08x %10d %10d\n",
buffer.sample_no,time_str,
buffer.pc,buffer.bio,
buffer.dio);
}
} while(ios.iosb$w_status != SS$_ENDOFFILE);
return(SS$_NORMAL);
}
|
Example 21.
Build Process
$
$ cc pc_tester
$ cc stub
$ cc pc_sampler3
$ link pc_tester,stub,pc_sampler3
$
$ cc pc_logger2
$ link pc_logger2
$
$ cc pc_listener
$ link pc_listener
$
|
Example 22. Sample Runs
$ r pc_tester
$ pc_dump sample.data
Sample Time of Sample PC BIO DIO
------ -------------- -- --- ---
00000001: 1-SEP-2004 23:39:00.33 000300f0 3013 4625
00000002: 1-SEP-2004 23:39:01.33 00030110 3014 4625
00000003: 1-SEP-2004 23:39:02.33 00030150 3015 4625
00000004: 1-SEP-2004 23:39:03.34 00030150 3016 4625
00000005: 1-SEP-2004 23:39:04.34 00030104 3017 4625
00000006: 1-SEP-2004 23:39:05.34 00030110 3018 4625
00000007: 1-SEP-2004 23:39:06.34 00030150 3019 4625
00000008: 1-SEP-2004 23:39:07.34 000300f0 3020 4625
00000009: 1-SEP-2004 23:39:08.36 00030150 3021 4625
00000010: 1-SEP-2004 23:39:09.36 00030100 3022 4625
00000011: 1-SEP-2004 23:39:10.36 00030110 3023 4625
00000012: 1-SEP-2004 23:39:11.36 00030150 3024 4625
00000013: 1-SEP-2004 23:39:12.36 00030110 3025 4625
00000014: 1-SEP-2004 23:39:13.36 00030104 3026 4625
***** No more data *****
$
|
The Listener is run
independently from another terminal session and picks up the data as it comes
in.
Example 23.
Sample PC_LISTENER Runs
$ r pc_listener
00000010: 1-SEP-2004 23:39:09.36 00030100 3022 4625
00000011: 1-SEP-2004 23:39:10.36 00030110 3023 4625
00000012: 1-SEP-2004 23:39:11.36 00030150 3024 4625
00000013: 1-SEP-2004 23:39:12.36 00030110 3025 4625
00000014: 1-SEP-2004 23:39:13.36 00030104 3026 4625
*** No more Data ***
$
Sample run with the sampler inactive.
$ r pc_listener
Logger is not active. Try again later.
%SYSTEM-F-NOLISTENER, specified remote system process not listening
$
$ r pc_tester
$ pc_dump sample.data
Sample Time of Sample PC BIO DIO
------ -------------- -- --- ---
00000001: 1-SEP-2004 23:40:05.92 00030104 3113 4631
00000002: 1-SEP-2004 23:40:06.92 00030100 3114 4631
00000003: 1-SEP-2004 23:40:07.93 00030104 3115 4631
00000004: 1-SEP-2004 23:40:08.93 00030150 3116 4631
00000005: 1-SEP-2004 23:40:09.93 000300f0 3117 4631
00000006: 1-SEP-2004 23:40:10.93 00030150 3118 4631
00000007: 1-SEP-2004 23:40:11.94 000300f0 3119 4631
00000008: 1-SEP-2004 23:40:12.94 000300f0 3120 4631
00000009: 1-SEP-2004 23:40:13.94 00030150 3121 4631
00000010: 1-SEP-2004 23:40:14.94 00030100 3122 4631
00000011: 1-SEP-2004 23:40:15.94 000300f0 3123 4631
00000012: 1-SEP-2004 23:40:16.94 00030110 3124 4631
00000013: 1-SEP-2004 23:40:17.94 000300f0 3125 4631
00000014: 1-SEP-2004 23:40:18.95 00030150 3126 4631
***** No more data *****
$
|
Again, this is run
from another session.
$ r pc_listener
00000007: 1-SEP-2004 23:40:11.94 000300f0 3119 4631
00000008: 1-SEP-2004 23:40:12.94 000300f0 3120 4631
00000009: 1-SEP-2004 23:40:13.94 00030150 3121 4631
00000010: 1-SEP-2004 23:40:14.94 00030100 3122 4631
00000011: 1-SEP-2004 23:40:15.94 000300f0 3123 4631
00000012: 1-SEP-2004 23:40:16.94 00030110 3124 4631
00000013: 1-SEP-2004 23:40:17.94 000300f0 3125 4631
00000014: 1-SEP-2004 23:40:18.95 00030150 3126 4631
*** No more Data ***
$
|
|
|
|
|
|
|
On Mailboxes go to: http://h71000.www7.hp.com/doc/os83_index.html
Consult the following Manuals:
HP OpenVMS I/O User's Reference Manual
HP OpenVMS Programming Concepts Manual
HP OpenVMS System Services Reference Manual
To contact the author send email to: Bruce.Ellis@BRUDEN.com
|
|
» Send feedback to about this article
|
