If your server was previously running PATHWORKS (LAN Manager), and you encounter a problem that is completely unsolvable, you can remove the newly installed software using the Rollback command procedure provided with PATHWORKS Advanced Server. The Rollback procedure must have been enabled during the server installation procedure. Refer to the Compaq PATHWORKS for OpenVMS (Advanced Server) Server Migration Guide for information about reverting to the previous version of the server.

The Advanced Server allows you to make adjustments to the server software configuration after running the server configuration procedure, PWRK$CONFIG.COM. You can use the Configuration Manager (invoked by the ADMINISTER/CONFIGURATION command) to modify parameters affecting the system environment. You can edit the LANMAN.INI file to modify server-specific parameters that are not modifiable with PWRK$CONFIG.

This chapter explains how to use Configuration Manager and how to modify the parameters stored in the LANMAN.INI file. This chapter includes the following sections:

• Section 7.1, Overview of Server Configuration, describes the server configuration environment and distinguishes the server system-specific parameters that are modifiable using the Configuration Manager (ADMINISTER/CONFIGURATION) from the server-specific LANMAN.INI parameters.
• Section 7.2, Using the Configuration Manager, describes how to use the Configuration Manager to manage the server's system environment configuration.
• Section 7.3, Using the LANMAN.INI File, describes the structure of the LANMAN.INI file and how to modify its contents.

The PWRK$CONFIG configuration procedure allows you to modify parameters that determine the server's system environment and parameters affecting the initial configuration of the server itself.

7.1.1 Server System Environment Parameters

When the PWRK$CONFIG.COM configuration procedure prompts you whether you want to "change server configuration parameters," it is giving you the option to modify the system environment parameters, using the Configuration Manager, a character-cell user interface. These are server-specific parameters that are not stored in the LANMAN.INI file. These parameters are, for the most part, directly or indirectly related to the environment in which the Advanced Server operates, such as the server's usage of OpenVMS system resources (physical memory, for example). Examples of these parameters include the server's client capacity, the size of its data cache, and which network transports it should use.

You can adjust these parameters after running PWRK$CONFIG by invoking the Configuration Manager with the ADMINISTER/CONFIGURATION command.

7.1.2 Server-Specific LANMAN.INI Configuration Parameters

The main function of the PWRK$CONFIG.COM configuration procedure is to let you set up or modify your initial Advanced Server configuration. For example, it allows you to specify:

• Whether to run the License Server
• Whether to enable specific services
• The domain name
• The server role in the domain
• The computer name
• The server cluster alias
• The server description

Your responses to the PWRK$CONFIG.COM configuration procedure prompts determine the values of parameters (keywords) stored in the LANMAN.INI file. The LANMAN.INI stores other server-specific parameters that are not modified by means of the PWRK$CONFIG.COM configuration procedure. The defaults for these parameters are appropriate for most typical environments. However, you can modify these by editing the LANMAN.INI file. These parameters affect the behavior of the Advanced Server but not, for the most part, file server resource consumption. These include parameters that affect Browser activity, network logon, and the function of other services; and values that define the shares created automatically by the Advanced Server.

When the PATHWORKS Advanced Server is installed, the LANMAN.INI file contains values for certain parameter keywords. Other keywords, and the titles of the sections to which they belong, are added when you run the Configuration Manager or edit the LANMAN.INI file. If a keyword does not appear in the file (or is commented out with a semicolon), it is set to its default value.

7.2 Using the Configuration Manager

The Configuration Manager has a character-cell user interface. If you are using DECterm or an equivalent terminal emulator, you can access all the functions of the Configuration Manager using a mouse input device. If you are using a keyboard to control the Configuration Manager, see Section 7.2.8, Navigating the Configuration Manager Using a Keyboard, for information about the keys you can use to control the Configuration Manager.

The server parameters you can modify using the Configuration Manager include:

• Basic configuration parameters, including:
  • The client capacity of the server
  • The percentage of free physical memory to be considered available to the server
  • The size of the server's data cache
  • The maximum number of concurrent user signons
  • The OpenVMS process priority for the server process
• Advanced configuration parameters, including:
  • Enabling and disabling open file caching, which delays the actual closing of user files
  • The time interval controlling open file caching
  • The average number of files allowed open per client
  • The average number of byte range locks held per client
  • Enabling and disabling dynamic security upgrading of PATHWORKS V5 for OpenVMS (LAN Manager) files
  • The security model that the server uses at the file access level
• Transport parameters, including:
  • The selection of transports enabled
  • The wide-area networking (WAN) capabilities of the server, if any

Each type of parameter is presented on a separate screen by the Configuration Manager. Each parameter is described in more detail in a later section.

7.2.1 Starting the Configuration Manager

To start the Configuration Manager, log in to the OpenVMS SYSTEM account, or to an account with similar privileges, and enter the following command:

$ ADMINISTER/CONFIGURATION

The screen shown in Figure 7-1, Basic Configuration Parameters Screen, appears.

Figure 7-1 Basic Configuration Parameters Screen

The Basic Configuration Parameters screen allows you to modify the basic server configuration parameters and provides access to the Advanced Configuration Parameters screen and the Transport Configuration Parameters screen. It allows you to verify the current configuration settings or to quit the Configuration Manager without changing any configuration settings, and provides online help information through the Help menu.

7.2.2 Exiting the Configuration Manager

To exit the Configuration Manager, select one of the following buttons on the Basic Configuration Parameters screen, and press the Enter or Return key:

• The Verify button allows you to verify and save the configuration you have established. For more information about saving and verifying your parameter settings, see Section 7.2.7, Verifying and Saving the New Configuration.
• The Quit button allows you to exit the Configuration Manager without saving your changes to the server parameters. To quit the Configuration Manager, select the Quit command button and press the Enter or Return key, choose the Quit menu item in the Options menu, or press Ctrl/Z.

To get help while running the Configuration Manager, select the Help menu at the top of the Basic Configuration Parameters screen.

From the Help menu, you can choose to display the following types of information:

• The Overview menu item describes the purpose and operation of the Configuration Manager.
• The Basic configuration menu item describes the server parameters you change on the Basic Configuration Parameters screen.
• The Advanced configuration menu item describes the server parameters you change on the Advanced Configuration Parameters screen.
• The Transport configuration menu item describes the server parameters you change on the Transport Configuration Parameters screen.

The following sections describe each screen and each parameter in detail.

7.2.4 Modifying Basic Configuration Parameters

The first screen that appears when you start the Configuration Manager is the Basic Configuration Parameters screen. It allows you to change the basic server configuration parameters, as described in the following sections.

7.2.4.1 Specifying a Server's Client Capacity

Client capacity is the maximum number of client sessions the server can support at a time. You can enter a value, or you can let the Configuration Manager determine a value based on current resources.

To specify the client capacity, on the Basic Configuration Parameters screen:

1. Select User Supplied Client Capacity.
2. Enter the new value in the Client Capacity text box.

The Configuration Manager may need to run AUTOGEN or reboot your system to make additional resources available to support such a configuration.

To allow the Configuration Manager to determine the appropriate setting, select one of the following:

• Maximize Client Capacity Using AUTOGEN or Reboot
  Determines the maximum number of clients the server can accommodate simultaneously given the maximum resource capacity of your system. The Configuration Manager may need to run AUTOGEN, reboot your system, or do both, to make additional resources available to support such a configuration.
• Maximize Client Capacity Without Using AUTOGEN/Reboot
  Determines the maximum number of clients the server can accommodate simultaneously, using the system resources currently being accessed. You do not need to run AUTOGEN or reboot the system for such a configuration.

To determine the maximum number of clients, use the following procedure:

1. Make sure the values on the Advanced Configuration Parameters screen and the Transport Configuration Parameters screen are correct.
2. Choose one of the Client Capacity option buttons on the Basic Configuration Parameters screen to control the way the determination will be made.
3. Select the Verify command button to verify and save the server parameter settings, as described in Section 7.2.7, Verifying and Saving the New Configuration.

After you determine the maximum number of clients the server will accommodate, be sure that the network transports you want to use can accept at least this many links. If not, configure the transports to accept more links.

• For the DECnet family of products, the configuration change depends on the version of DECnet. For DECnet Phase IV, the default maximum number of transport links is 32. For this version of DECnet, you can configure the transport to accept 100 links by entering the following commands:

  $ MCR NCP DEFINE EXECUTOR MAXIMUM LINKS 100 $ MCR NCP SET EXECUTOR MAXIMUM LINKS 100

• For DECnet-Plus, the default maximum number of transport links is 200. To raise this maximum to 300, enter the following commands:

  $ MCR NCL SET NODE 0 NSP MAXIMUM RECEIVE BUFFERS 6000 $ MCR NCL SET NODE 0 NSP MAXIMUM TRANSPORT CONNECTIONS 300


  Note that the number of receive buffers should be set to 20 * n, where n is the maximum number of transport connections. In addition, be sure to edit the NET$LOGICALS.COM file to increase the NET$ACP quotas appropriately.

For more information about configuring the DECnet transport, refer to the Compaq DECnet for OpenVMS Network Management Utilities manual.

7.2.4.2 Specifying the Percent of Physical Memory Used

The Configuration Manager allows you to specify the maximum percentage of the system's physical memory that the configuration may use, primarily for the number of clients and the data cache size. For example, if you set the value to 50%, and your Advanced Server currently has 200 MB of free memory available (when the Configuration Manager verifies the configuration), the Configuration Manager allows a maximum of 100 MB of memory to be available to support the number of clients and data cache size currently configured for the server.

If, in the preceding example, the Configuration Manager determines that 100 MB is not enough to support the currently configured client capacity and data cache size, then you can do either of the following:

• Increase the percentage of physical memory used
• Reduce the number of supported clients and/or the data cache size to accommodate the percentage of physical memory available.

You can specify from 1% to 100% of physical memory. If you set the maximum percentage value too high, other OpenVMS applications might not have enough memory to operate. The default setting is 80%.

To modify the percentage of physical memory the server may use, on the Basic Configuration Parameters screen, enter the percent value in the Percent of Physical Memory Used field.

7.2.4.3 Specifying Server Data Cache Size

The Configuration Manager allows you to specify the size of the data cache for the server's file data. A proper setting can decrease the amount of disk I/O, improving server response. You can set this value from 512 Kbytes to 131,072 Kbytes (128 Mbytes). The default setting is 2048 Kbytes (2 Mbtyes). Compaq recommends a minimum of 128 Kbytes of cache per concurrent client session. For example, if you expect 200 concurrent client sessions, set the data cache size to at least 25,600 Kbytes. When the Advanced Server starts, it allocates pages directly off the free page list to create the data cache. For more information about setting the data cache size, see Section 6.2.2.3.1, Monitoring Data Cache Use by the File Server.

To modify server data cache size, on the Basic Configuration Parameters screen, enter the number of Kbytes in the Data Cache Size field.

7.2.4.4 Specifying the Maximum Number of Concurrent Signons

The Configuration Manager allows you to specify the maximum number of external authentication signon operations that can take place concurrently. External authentication allows the Advanced Server to do the logon validation for both network accounts and OpenVMS user accounts. For more information about external authentication, see Section 3.1.17, External Authentication.

You can enter any number from 2 through 999. The default value for this parameter is 10.

To modify the maximum number of concurrent signons, on the Basic Configuration Parameters screen, enter the new value in the Maximum Concurrent Signons field.

7.2.4.5 Specifying OpenVMS Process Priority

The Configuration Manager allows you to specify the base priority assigned to main server processes for scheduling purposes. Values from 9 to 12 are most appropriate. Server processes below base priority 9 can be preempted by interactive processes, and processes above base priority 12 will not receive their priority boosts.

To change the base process priority for the server, on the Basic Configuration Parameters screen, enter the value in the OpenVMS Process Priority field.

7.2.5 Modifying Advanced Configuration Parameters

The Advanced Configuration Parameters screen allows you to modify configuration parameters that are less frequently modified. To change advanced parameters, select the Advanced command button on the Basic Configuration Parameters screen. The screen shown in Figure 7-2, Advanced Configuration Parameters Screen, appears.

Figure 7-2 Advanced Configuration Parameters Screen

The following sections describe the advanced configuration parameters and how to set them.

7.2.5.1 Enabling and Disabling Open File Caching

When Open File Caching is enabled, the server delays the actual closing of files in case they are reopened shortly. Open File Caching is enabled by default. You can disable Open File Caching by deselecting the Use Open File Caching option on the Advanced Configuration Parameters screen.

To enable or disable Open File Caching, on the Advanced Configuration Parameters screen, select Use Open File Caching. The check box contains an X when open file caching is enabled.

7.2.5.2 Setting the Open File Caching Interval

When Open File Caching is enabled, you can specify the amount of time to delay the actual closing of files. The default setting is 5000 msec (milliseconds), which is 5 seconds. You can specify from 0 to 65,535 milliseconds.

To modify the Open File Caching interval, on the Advanced Configuration Parameters screen:

1. Be sure that the Use Open File Caching option is checked.
2. Enter the number of milliseconds to delay in the Open File Caching Interval field.

The Configuration Manager allows you to specify the average number of files open per client. This value is used to compute values for a number of other parameters having to do with open files and file I/O. You can specify any nonzero value for this parameter; the default average is 12 open files per client.

To modify the Files per Client value, on the Advanced Configuration Parameters screen, enter the new value in the Files per Client field.

7.2.5.4 Specifying the Byte Range Locks per Client

The Configuration Manager allows you to specify the average number of byte range locks held per client. Byte range locks are used by client applications for locking portions of open shared files. You can specify any nonzero value for this parameter; the default is 6 byte range locks per client.

To modify the value of Byte Range Locks per Client, on the Advanced Configuration Parameters screen, enter the new value in the Byte Range Locks per Client field.

7.2.5.5 Enabling Dynamic Security Upgrade

The Configuration Manager allows you to specify whether the server performs dynamic upgrading of network security on files it accesses. When enabled, any file the server accesses whose security is specified entirely according to PATHWORKS V5 for OpenVMS (LAN Manager) security, is upgraded to PATHWORKS V6 for OpenVMS (Advanced Server) security. The mapping file created by the V6 Upgrade utility must be in place for dynamic security upgrade to be performed. Refer to the Compaq PATHWORKS for OpenVMS (Advanced Server) Server Migration Guide for more information about the Upgrade utility. By default, dynamic security upgrade is not enabled.

To enable or disable Dynamic Security Upgrade, on the Advanced Configuration Parameters screen, select the Enable Dynamic Security Upgrade option. The check box contains an X when dynamic security upgrading is enabled.

7.2.5.6 Specifying the Server Security Model

The Configuration Manager lets you specify the security model that the server uses when checking access to a file, as shown in Table 7-1, Security Model Configuration Parameter Settings.

For more information about the security models, see Section 4.1.2,Advanced Server Security Models.

To select the server security model, on the Advanced Configuration Parameters screen, select either Advanced Server Only or Advanced Server and OpenVMS.

7.2.5.7 Saving Advanced Configuration Parameter Changes

You can save the Advanced Configuration Parameters you have modified, or you can quit without saving your changes.

To save advanced configuration parameters changes, on the Advanced Configuration Parameters screen, select the OK button. If any setting is not appropriate, the Configuration Manager displays an Information screen (such as shown in Figure 7-5, Information Screen. If all the settings are appropriate, the Basic Configuration Parameters screen reappears.

To ignore advanced configuration parameters changes, on the Advanced Configuration Parameters screen, select the Cancel button or press Ctrl/C. The Basic Configuration Parameters screen reappears.

7.2.6 Configuring Transports

The Transport Configuration Parameters screen allows you to specify the types of transports that are enabled on the server, and the type of wide-area network capabilities, if any. To change the transport parameters, select the Tranports command button on the Basic Configuration Parameters screen. The Transport Configuration Parameters screen appears, such as the one shown in Figure 7-3, Transport Configuration Parameters Screen.

Figure 7-3 Transport Configuration Parameters Screen

The transport configuration parameters are described in the following sections.

7.2.6.1 Enabling and Disabling Transports

The Configuration Manager lets you enable or disable one or more of the following transports: DECnet, NetBEUI, TCP/IP. (Note that for wide area networking, the TCP/IP transport is required. DECnet also supports wide area networks but the functionality it provides is not as extensive as that provided by TCP/IP. NetBEUI is recommended only for use in small LAN-only environments (approximately 50 nodes or less).) For more information about transports and the protocols they support, see Appendix A, Network Protocols.

To enable and disable a transport, on the Transport Configuration Parameters screen, select the transport names. The transport is enabled if the check box contains an X.
