        .TITLE  LAN SAMPLE TEST PROGRAM        .IDENT  /X02/        .PSECT  RWDATA,WRT,NOEXE,PAGE; This LAN test program sends a MOP loopback message to the Loopback Assistant; Multicast address and waits for a response.  The program uses the LAN device; EWA0.  To use a different device, change the device name in the program or; define the desired lan device as EWA0.;; To build on VAX or Alpha:;        $ MACRO LANETH;        $ LINK LANETH        .LIBRARY "SYS$LIBRARY:LIB.MLB"        $IODEF                          ; Define I/O functions and modifiers        $NMADEF                         ; Define Network Management parameters; Setmode parameter buffer and descriptor.  Since the loopback protocol does; not include a length word following the protocol type, we have to explicitly; turn off padding since the default is on.SETPARM:        .WORD   NMA$C_PCLI_FMT          ; Packet format        .LONG   NMA$C_LINFM_ETH         ;   Ethernet        .WORD   NMA$C_PCLI_PTY          ; Protocol type        .LONG   ^X0090                  ;   Loopback        .WORD   NMA$C_PCLI_PAD          ; Padding        .LONG   NMA$C_STATE_OFF         ;   OffSETPARMLEN = .-SETPARMSETPARMDSC:        .LONG   SETPARMLEN        .ADDRESS SETPARM; Sensemode parameter buffer and descriptor.  This is  used to get our physical; address to put into the loopback message.SENSEBUF:        .BLKB   512SENSELEN=.-SENSEBUFSENSEDSC:        .LONG   SENSELEN        .ADDRESS SENSEBUF; P2 transmit data buffer.XMTBUF: .WORD   00                      ; Skip count        .WORD   02                      ; Forward requestFORW:   .BLKB   6                       ; Forward address        .WORD   01                      ; Reply request        .WORD   00XMTBUFLEN = .-XMTBUF                    ; Size of transmit buffer; P5 transmit destination address, the Loopback Assistant Multicast Address.XMTP5:  .BYTE   ^XCF,0,0,0,0,0; P2 receive data buffer.RCVBUF: .BLKB   512RCVBUFLEN = .-RCVBUF                    ; Size of receive buffer; P5 receive header buffer.RCVP5:RCVDA:  .BLKB   6RCVSA:  .BLKB   6RCVPTY: .BLKB   2; Messages used to display status of this program.GMSG:   .ASCID  "Successful test"LMSG:   .ASCID  "No response"EMSG:   .ASCID  "Error occurred while running test"DMSG:   .ASCID  "LAN device not found"; Miscellaneous data.IOSB:   .BLKQ   1                       ; I/O status blockDEVCHAN:.BLKL   1                       ; Returned port numberLANDSC: .ASCID  'EWA0'                  ; Device to use for test;*************************************************************************;; Start of code;;*************************************************************************        .PSECT  CODE,EXE,NOWRT,PAGE        .ENTRY  START,^M<>; Assign a port to the LAN device.        $ASSIGN_S DEVNAM=LANDSC,CHAN=DEVCHAN        BLBS    R0,10$                  ; Branch if succeeded        MOVAL   DMSG,R9                 ; Get address of error message        BRW     EXIT                    ; Print message and exit; Set up the port's characteristics.10$:    MOVAL   EMSG,R9                 ; Assume error message address        $QIOW_S FUNC=#<IO$_SETMODE!IO$M_CTRL!IO$M_STARTUP>,-                CHAN=DEVCHAN,IOSB=IOSB,-                P2=#SETPARMDSC        BLBC    R0,20$                  ; Branch if failed        MOVZWL  IOSB,R0                 ; Get status from IOSB        BLBS    R0,30$                  ; Branch if succeeded20$:    BRW     EXIT                    ; Print message and exit; Issue the SENSEMODE QIO to get our physical address for the loopback; message.30$:    $QIOW_S FUNC=#<IO$_SENSEMODE!IO$M_CTRL>,-                CHAN=DEVCHAN,IOSB=IOSB,-                P2=#SENSEDSC        BLBC    R0,20$                  ; Branch if failed        MOVZWL  IOSB,R0                 ; Get status from IOSB        BLBC    R0,20$                  ; Branch if failed; Locate the PHA parameter in the SENSEMODE buffer and copy it into the; LOOPBACK transmit message.  The PHA parameter is a string parameter.        MOVAB   SENSEBUF,R0             ; Start at beginning of buffer40$:    BBS     #^XC,(R0),50$           ; Branch if a string parameter        ADDL    #6,R0                   ; Skip over longword parameter        BRB     40$                     ; Check next parameter50$:    BICW3   #^XF000,(R0)+,R1        ; Get type field less flag bits        CMPW    R1,#NMA$C_PCLI_PHA      ; Is this the PHA parameter?        BEQL    60$                     ; Branch if so        ADDW    (R0)+,R0                ; Skip over string parameter        BRW     40$                     ; Check next parameter60$:    MOVL    2(R0),FORW              ; Copy our address to the loopback        MOVW    6(R0),FORW+4            ; packet we are about to transmit; Transmit the loopback message.        $QIOW_S FUNC=#IO$_WRITEVBLK,CHAN=DEVCHAN,IOSB=IOSB,-                P1=XMTBUF,P2=#XMTBUFLEN,P5=#XMTP5        BLBC    R0,70$                  ; Branch if failed        MOVZWL  IOSB,R0                 ; Get status from IOSB        BLBS    R0,80$                  ; Branch if succeeded70$:    BRW     EXIT                    ; Print message and exit; Look for a response.  We use the NOW function modifier on the READ so that; we don't hang here waiting forever if there is no response.  If there is no; response in 1000 receive attempts, we declare no response status.80$:    MOVL    #1000,R2                ; Check 1000 times90$:    $QIOW_S FUNC=#IO$_READVBLK!IO$M_NOW,CHAN=DEVCHAN,IOSB=IOSB,-                P1=RCVBUF,P2=#RCVBUFLEN,P5=#RCVP5        BLBC    R0,EXIT                 ; Branch if failed        MOVZWL  IOSB,R0                 ; Get status from IOSB        BLBS    R0,100$                 ; Branch if succeeded        CMPL    R0,#SS$_ENDOFFILE       ; Was there just no message available?        BNEQ    EXIT                    ; Branch if failed        SOBGTR  R2,90$                  ; Try again; No response in 1000 attempts.        MOVAL   LMSG,R9                 ; Get address of lost message        BRW     EXIT                    ; Print message and exit; Received a message.100$:   MOVAL   GMSG,R9                 ; Get address of success message; The test is done.  Call LIB$PUT_OUTPUT to display the test status.EXIT:   PUSHL   R9                      ; P1 = Address of message to print        CALLS   #1,G^LIB$PUT_OUTPUT     ; Print the message        $EXIT_S                         ; Exit        .END    START

/************************************************************* * LAN Sample Test Program * * This LAN test program sends a MOP loopback message to the Loopback Assistant * Multicast address and waits for a response.  The program uses the LAN device * EWA0.  To use a different device, change the device name in the program or * define the desired lan device as EWA0. * * To build on VAX:                 To build on Alpha: *    $ CC LAN802E                     $ CC LAN802E + SYS$LIBRARY:SYS$LIB_C.TLB/LIB *    $ LINK LAN802E,SYS$INPUT:/OPT    $ LINK LAN802E *      SYS$SHARE:VAXCRTL.EXE/SHARE *************************************************************/#include <ctype>                        /* Character type classification macros/routines */#include <descrip>                      /* For VMS descriptor manipulation */#include <iodef>                        /* I/O function code definitions */#include <ssdef>                        /* System service return status code definitions */#include <starlet>                      /* System library routine prototypes */#include <stdio>                        /* ANSI C Standard Input/Output */#include <stdlib>                       /* General utilities */#include <string>                       /* String handling */#include <stsdef>                       /* VMS status code definitions */#define NMA$C_PCLI_FMT 2770#define NMA$C_PCLI_PID 2774#define NMA$C_PCLI_PHA 2820#define NMA$C_LINFM_802E 0#define $SUCCESS(status) (((status) & STS$M_SUCCESS) == SS$_NORMAL)#define $FAIL(status) (((status) & STS$M_SUCCESS) != SS$_NORMAL)#pragma nomember_alignmentstruct parm_802e{    short pcli_fmt;                     /* Format - 802E */    int fmt_value;    short pcli_pid;                     /* Protocol ID - 08-00-2B-90-00 */    short pid_length;    char pid_value[5];} setparm_802e = {NMA$C_PCLI_FMT, NMA$C_LINFM_802E,NMA$C_PCLI_PID, 5, 8,0,0x2b,0x90,0};struct setparmdsc{    int parm_len;    void *parm_buffer;};struct setparmdsc setparmdsc_loop = {sizeof(setparm_802e),&setparm_802e};struct p5_param                         /* P5 Receive header buffer */{    unsigned char da[6];    unsigned char sa[6];    char misc[20];};struct iosb                             /* IOSB structure */{    short w_err;                        /* Completion Status */    short w_xfer_size;                  /* Transfer Size */    short w_addl;                       /* Additional status */    short w_misc;                       /* Miscellaneous */};struct ascid                            /* Device descriptor for assign */{    short w_len;    short w_info;    char *a_string;} devdsc = {4,0,"EWA0"};struct iosb qio_iosb;                   /* IOSB structure */struct p5_param rcv_param;              /* Receive header structure */struct p5_param xmt_param={             /* Transmit header structure */  0xCF,0,0,0,0,0};                      /* Loopback Assistant Multicast Address */char rcv_buffer[512];                   /* Receive buffer */char xmt_buffer[20]={                   /* Transmit buffer */  0,0,                                  /* Skip count */  2,0,                                  /* Forward request */  0,0,0,0,0,0,                          /* Forward address */  1,0,                                  /* Reply request */  0,0};char sense_buffer[512];                 /* Sensemode buffer */struct setparmdsc sensedsc_loop = {sizeof(sense_buffer),&sense_buffer};/* * MAIN */main(int argc, char *argv[]){    int i, j;                           /* Scratch */    int chan;                           /* Channel assigned */    int status;                         /* Return status */    /*     * Start a channel.     */    status = sys$assign(&devdsc,&chan,0,0);    if ($FAIL(status)) exit(status);    status = sys$qiow(0,chan,IO$_SETMODE|IO$M_CTRL|IO$M_STARTUP,&qio_iosb,0,0,0,                      &setparmdsc_loop,0,0,0,0);    if ($SUCCESS(status)) status = qio_iosb.w_err;    if ($FAIL(status))    {        printf("IOSB addl status = %04X %04X (on startup)\n",qio_iosb.w_addl,qio_iosb.w_misc);        exit(status);    }    /*     * Issue the SENSEMODE QIO to get our physical address for the loopback message.     */    status = sys$qiow(0,chan,IO$_SENSEMODE|IO$M_CTRL,&qio_iosb,0,0,0,                      &sensedsc_loop,0,0,0,0);    if ($SUCCESS(status)) status = qio_iosb.w_err;    if ($FAIL(status))    {        printf("IOSB addl status = %04X %04X (on sensemode)\n",                                   qio_iosb.w_addl,qio_iosb.w_misc);        exit(status);    }    /*     * Locate the PHA parameter in the SENSEMODE buffer and copy it into the     * LOOPBACK transmit message.  The PHA parameter is a string parameter.     */    j = 0;    while (j < sizeof(sense_buffer))    {        i = (sense_buffer[j] + (sense_buffer[j+1]<<8));        if (0x1000 & i)        {            if ((i & 0xFFF) == NMA$C_PCLI_PHA)            {                memcpy(&xmt_buffer[4],&sense_buffer[j+4],6);                break;            }            j += (sense_buffer[j+2] + (sense_buffer[j+3]<<8)) + 4;        }        else        {            j += 6;                     /* Skip over longword parameter */        }    }    /*     * Transmit the loopback message.     */    status = sys$qiow(0,chan,IO$_WRITEVBLK,&qio_iosb,0,0,&xmt_buffer[0],             sizeof(xmt_buffer),0,0,&xmt_param,0);    if ($SUCCESS(status)) status = qio_iosb.w_err;    if ($FAIL(status))    {        printf("IOSB addl status = %04X %04X (on transmit)\n",                                   qio_iosb.w_addl,qio_iosb.w_misc);        exit(status);    }    /*     * Look for a response.  We use the NOW function modifier on the READ so that     * we don't hang here waiting forever if there is no response.  If there is no     * response in 1000 receive attempts, we declare no response status.     */    for (i=0;i<1000;i++)    {        status = sys$qio(0,chan,IO$_READVBLK|IO$M_NOW,&qio_iosb,0,0,&rcv_buffer[0],                 sizeof(rcv_buffer),0,0,&rcv_param,0);        if ($SUCCESS(status)) status = qio_iosb.w_err;        if ($SUCCESS(status)) break;    }    if ($SUCCESS(status))        printf("Successful test\n");    else        printf("No response\n");}
