DEChub 90: DECrepeater 90T

DECrepeater 90T

The DECrepeater 90T is a 9-port repeater with eight Unshielded Twisted Pair (UTP) 10baseT ports and one 10base2 port.

Photos

Front | Back | Top

Documentation

• DECrepeater 90T Operators Manual, Revision 001, August 1991

DECrepeater 90T+

The 90T+ is exactly the same as the 90T except that it supports sheilded twisted pair (STP) in addition to unshielded twisted pair. The 90T only supports Unshielded twisted pair (UTP).

Documentation

• DECrepeater 90T and 90T+ Owner's Manual, EK-DETMR-OM.C01, December 1992

DECrepeater 90T-16

The DECrepeater 90T-16 is a sixteen port 10baseT repeater. It also contains an additional 10base2 port on its side. It essentially seems to be the same as the DECrepeater 90T except slightly newer and with an additional eight ports. All ports are Shielded Twisted Pair.

Photos

Front | Back

Documentation

• DECrepeater 90T-16 Installation Guide, Revision A01 - EK-DETML-IN.A01 - May 1995
